Clamp Force Test Machine
Design Standatd:
ASTM D6055-2019,ISTA 6 Amazon, ISTA 6- SAMS CLUB, ISTA 3J GENERL SPECIFICATIONS
Applications:
Clamping Force Testing Machine for packaging simulates the transportation with Schnabel car discharge the package, in the transit, the package of box affected by clamping force of both boards. And this clamping force tester is to evaluate the resistance property of the package toward this clamping force.
Specifications:
Capacity: 18kN
Control System: Computer control
Motor: Panasonic 750W servo motor
Load Cell Resolution: 1/250,000
Clamping Plate Size: Approximate 1220mm x 1220mm (LxW)
Clamping Space:
Minimum about 50mm×1220mm×1220mm (L*W*H)
Maximum about 2000mm×1220mm×1220mm (L*W*H)
Clamping Speed: 5~500mm/min (adjustable)
Lifting Height: 50~1000mm
Lifting Speed:
Rise: 5~600mm/min (adjustable)
Drop: 5~300mm/min (adjustable)
Lifting Method: Cylinder drive
Hydraulic Unit Combination: 2.2kW (3HP); 40L fuel tank
