Antistatic powder coating
Antistatic Powder Coating is formulated with conductive and antistatic functional materials to effectively control static electricity accumulation on coated surfaces. You can use this coating in both indoor and outdoor environments where electrostatic discharge must be minimized to protect sensitive instruments and equipment. The coating provides stable, long-term antistatic performance while maintaining reliable mechanical and environmental resistance.
Application
You can apply this antistatic powder coating to surfaces that require electrostatic control and durable protection, including:
-
Electrical appliances and housings
-
Electronic instruments and control cabinets
-
Laboratory equipment enclosures
-
Industrial automation components
-
Precision device casings
Test Substrate:
All performance tests were conducted on 0.8 mm degreased and rust-free cold-rolled steel panels with a coating thickness of 40–80 µm.
Parameters
| Item | Specification |
|---|---|
| Curing Conditions | 200 ℃ × 10–15 min |
| Spraying Method | High-voltage electrostatic spraying |
| Output Voltage | 60–80 kV |
| Recommended Film Thickness | 60–80 µm |
Physical Properties
| Item | Standard Requirement | Test Method |
|---|---|---|
| Pencil Hardness | ≥ H | ASTM D3363 |
| Impact Resistance | ≥ 50 kg·cm | ISO 6272 |
| Bend Resistance | ≤ 2 mm | ISO 1519 |
| Adhesion | Class 0 | ISO 2409 |
| Cupping Resistance | ≥ 6 mm | ISO 1520 |
Chemical & Environmental Properties
| Item | Requirement | Test Method |
|---|---|---|
| Salt Spray Resistance | ≥ 500 h, ≥ Rating 9 | ISO 9227 |
| Damp Heat Resistance | ≥ 1000 h, slight gloss loss only | ISO 6270 |
| Weathering Resistance (Outdoor) | QUV-B313 240 h ≥ Level 3 | ISO 11341 |
Note:Coating performance may vary slightly depending on gloss level.
Features
-
You achieve a coating volume resistivity of10⁶–10¹⁰ Ω·cm, effectively preventing static electricity buildup
-
You benefit fromlong-term antistatic stability, even under continuous use
-
You maintain good mechanical strength while controlling electrostatic discharge
-
You can use the coating for bothfunctional protection and surface finishing
-
You meet environmental compliance requirements, includingRoHS
Case
You can use this antistatic powder coating on electrical instrument housings to reduce static accumulation during operation. In laboratory and industrial environments, the coating helps protect internal components from electrostatic discharge while maintaining surface durability and appearance under routine handling and cleaning.
