Automatic Long Filament Curl Shrinkage Tester
Automatic Long Filament Curl Shrinkage Tester
The automatic long filament curl shrinkage tester is designed for measuring boiling water shrinkage rate, dry heat shrinkage rate, curl shrinkage rate, curl modulus, and curl stability of synthetic fibers (polyester, nylon, polypropylene). Features include automatic load adjustment, auto-loading, timing, length measurement, and zero calibration during testing. Results are calculated and printed automatically.
Applicable Standards
GB/T 6506，GB/T 6505，ASTM D6774-22
System Composition
Main unit
Two yarn frames
Lenvovo brand computer
Printer
Special constant-temperature oven (for dry heat/curl shrinkage tests)
Special constant-temperature water tank (for boiling water shrinkage tests)
Technical Specifications
| Load Capacity | 2.5-5000 cN (adjustable, auto-application), Accuracy: ±0.2 cN |
| Sample Length | 500×2 mm |
| Measurement Range | 0-150 mm |
| Test Parameters | Curl Shrinkage Rate (CC)%, Curl Modulus (CM)%, Curl Stability (CS)%, Thermal Shrinkage Rate (S)%, Mean Value, Standard Deviation, CV Value |
| Data Interface | Keyboard/mouse input, screen display, printer output |
| Batch Capacity | 30 specimens per batch |
| Power Requirement | Host: 220V, 50Hz, 0.5kW Compressed Air: 0.2-0.3MPa |
| Dimensions | 650×550×1770 mm (L×W×H) |
