Toyota Specialized Abrasion Tester-QINSUN
Standard
JIS L 0849(Japanese Industrial Standard for Abrasion Resistance of Textiles)
ISO 5470-2(Rubber- or Plastics-Coated Fabrics — Abrasion Resistance)
ASTM D4060(Standard Test Method for Abrasion Resistance of Organic Coatings)
Product Advantages
Unmatched Precision
Proprietary load cell technology (±0.005 N accuracy) captures subtle wear patterns, critical for coated materials and thin films.
Extreme Durability
Aircraft-grade aluminum frame and corrosion-resistant components withstand 24/7 industrial use.
Smart Automation
AI-driven test protocols adjust speed, pressure, and cycles in real time based on material feedback.
Universal Testing Capability
Handles substrates from ultra-thin polymers (10 µm) to reinforced composites (10 mm thickness).
Global Compliance
Pre-loaded JIS, ISO, and ASTM test modes with automatic report generation in 8 languages.
Product Features
Testing Modes
Rotary Abrasion: 1–200 RPM for flat surfaces (e.g., coatings, films).
Reciprocating Abrasion: 10–50 mm stroke for seams, edges, and 3D geometries.
Custom Waveforms: Programmable motion profiles for simulated real-world wear (e.g., gear teeth, bearing surfaces).
Real-Time Analytics
4K camera system (120 FPS) with AI-powered fuzz/pill detection and surface roughness mapping.
Data Ecosystem
Cloud-connected software stores 100.000+ test results, predicts wear life, and integrates with ERP/MES systems.
Safety & Sustainability
Low-energy mode (50% power reduction), self-cleaning chamber, and CE/UL/RoHS certification.
Technical Parameters
| Parameter | Specification |
|---|---|
| Load Cell Capacity | 0–100 N (±0.005 N accuracy) |
| Speed Range | 1–200 RPM (rotary) / 10–50 mm/s (reciprocating) |
| Stroke Length | 10–50 mm (±0.01 mm resolution) |
| Test Stations | 1 (expandable to 3 with optional kit) |
| Dimensions (L×W×H) | 900×700×1.600 mm |
| Weight | 350 kg |
| Operating Environment | 5–40°C, ≤85% RH (non-condensing) |
| Power Supply | 220V/110V AC, 50/60Hz, 3.2kW |
Accessories Included
Abrasive Kits
5× precision-ground steel wheels (for TABER®-equivalent testing).
10× sandpaper discs (P80–P2500 grit).
Calibration Tools
JIS/ISO-certified reference block, load cell verifier, and traceable certificate.
Sample Fixtures
Pneumatic clamps for flat/curved specimens, vacuum chuck for thin films.
Software Suite
AI analytics platform with wear simulation, ERP integration, and 8-language report generator.
Safety Bundle
Emergency stop, acoustic enclosure, and fume extraction port.
Ideal For
Automotive OEMs (paint, coating, and trim durability)
Aerospace manufacturers (composite panel testing)
Medical device makers (biocompatible polymer wear)
Research universities (advanced material innovation)
