Hexapod Tumbler test machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
Standard
BSEN 1471:1997: Evaluation of Appearance Changes in Floor Coverings
ISO 9405:2001: Floor Coverings – Determination of Appearance Change After Simulated Traffic
ISO 10361:2000: Carpet Appearance Evaluation Using Tumbler Testers
IWS/Wools of New Zealand Methods 247 & 251: Pile Fabric Abrasion Resistance
Application
Textile Industry: Assesses carpet pile integrity for residential, commercial, and automotive applications.
Quality Control: Validates compliance with international appearance change standards.
Research & Development: Tests material resistance to abrasion, crushing, and pile distortion.
Certification Labs: Provides data for SATRA, ISO, and BSEN certification.
Product Advantages
Realistic Wear Simulation: Reciprocating mechanism replicates foot traffic and pile compression.
Rapid Testing: Completes substrate-based barrel tests within one working day.
Adjustable Parameters: Preset rotations (0–999.999 cycles) via digital counter.
Replaceable Components: Polyurethane hexapod feet (3.8 kg) last 2+ years and are easily replaceable.
Safety Design: Hinged cover with sensors prevents accidental access during operation.
Global Compliance: Meets BSEN, ISO, and IWS standards for carpet performance.
Product Features
Hexapod Foot Design: Six polyurethane feet (3.8 kg total) mimic human walking pressure.
Reciprocating Drum: Rotates at 35 ±2 RPM to simulate bidirectional traffic.
Substrate Testing: Accommodates steel balls or textile samples in the 200 mm deep chamber.
Digital Control: Touchscreen panel for cycle preset, speed adjustment, and real-time monitoring.
Easy Maintenance: Quick-release hexapod feet and corrosion-resistant stainless steel drum.
Wall Thickness: 8 mm drum construction ensures durability.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Panel | Touchscreen Timing Module |
| Hexapod Foot Weight | 3.8 kg (Six Polyurethane Feet) |
| Power Consumption | 0.5 kW |
| Rotational Speed | 35 ±2 RPM |
| Drum Internal Depth | 200 ±1 mm |
| Cycle Counter Range | 0–999.999 (Presettable) |
| Wall Thickness | 8 mm (Stainless Steel) |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 900 mm × 500 mm × 570 mm |
| Net Weight | 75 kg |
| Safety Cover |
Hinged with Sensor Interlock |
