High-efficiency Filter Test Bench - Test Equipment

•

Get a quote：

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Email: serving@qinsun-lab。com

The high-efficiency filter scanning test bench can test the efficiency and resistance of filters under the rated air volume conditions. The fundamental core of the test bench is particle counting. The dust source used in the test bench is liquid aerosol (DEHS) with a certain concentration, with a particle size of 0.1-0.3 μ m.

Meet the standards

It is designed and manufactured in accordance with the principles and requirements of the European standard EN1822-5 and in reference to relevant standards.

Parameter

1.Power supply voltage: Single-phase AC220V+5%; Three-phase AC380V+5% The power consumption is approximately 15kW

2. Power supply frequency :50Hz±2HZ

3. Applicable filter grade: High-efficiency filter

4. Aerosol particles :DEHS

5. Aerosol particle size :0.1-0.3 μ m

6. Test efficiency :(H13-U17) Note: ≥99.95%-≥99.999995%, MPPS

7. Test resistance: Range 0-1000Pa

Technical parameters of MPPS test bench

1.Flow rate :500-3500m ³ /h(refer to EN1822-5). Adjustment error: Adjustment accuracy ≤2%

2. Resistance measurement range :0-500Pa

3. Resistance: Measurement repeatability error 50-100Pa ±2Pa, {>}100Pa ≤3% (at rated flow)

4. Efficiency range :(H13-U17)(refer to EN1822-5

5. Counter sampling flow rate :28.3L/min±5%

6. Detection particle size range :0.1-0.3 μ m

7. Dimensions of the filter under test: Maximum :630(length)x630(width) Minimum :300(length)x300(width) According to the dimensions of the customer's product (dimensions between the maximum and minimum values can be tested by replacing the test fixture)

8. Data output: Printer

9. Overall power consumption :15KW

10. Floor area: Main structure, 13.000 x 3.000 x 3.000 (length x width x height)(estimated)

Function

1. Test filtration efficiency (MPPS）

2. Test the filtration resistance

3. Flow resistance curve
