Blanket Flammability Test Machine - Test Equipment

•

Bed Blanket Flammability Tester is used to detect the flame retardant performance of the bed blanket fabric and the flame spread property of the fabric surface. This test method is to burn the surface of the sample with a standardized flame within a specified time, thereby observing the burning, damage degree or discoloration of the standard test paper. And then, the test fabric is graded. Good repeatability of experimental data can help manufacturers effectively control production and verify product performance.

1. The instrument is mainly used to test the flame retardant performance of materials such as bed blankets. The front safety door of the instrument adopts a transparent observation window and a standard burner equipped with a flame ruler. The result can be used to evaluate the flame spread speed and damage length of the material after ignition under the standard, it provides data basis for new material research and development, product quality acceptance and the like.

2.The combustion box is made of stainless steel, high temperature resistant, smoke resistant, easy to clean after use, imported flow control accessories and timing module ensure accurate flow and time control of the instrument, and record the burning time. The instrument adopts button design. the ignition is automatically Reset after ignition, ready for the next test, easy to operate, easy to use, and efficient.

Standards

ASTM D4151

GB/T11049-2008.

BS 4790.

ISO 6925.

BS 6307.

Structure

Flowmeter :Adjust the gas flow size.

Fire tube : The gas is first connected to the flow meter through the hose, and then through the rear hose of the box into the flame pipe

Windscreen: the upper part of the windshield is provided with glass

The experiment was carried out in a ventilated kitchen. The round hole on the top of the box and the gap on the windshield make the gas convection.

Control panel :Power- power switch ;Start：Start internal motor operation. When the flame tube moves to the test position (the vertical distance from the sample center is 8mm, the horizontal distance is 3.2mm), the internal timing switch is touched;

Reset :Timer reset /Fire tube reset.

Sample clamp and specimen holder :The sample frame substrate is provided with a knob which can adjust the left and right movement, and the sample frame substrate is moved and fixed by loosening and tightening the knob.

Timer :Display settings and actual ignition time.After the time is cleared, the fire tube can complete the required movement. Or the fire tube can not return to the original position after moving forward.

Field Application

Bed Blanket Flammability Tester-It is mainly used for testing the flame retardant performance of bed blanket fabric and flame spreading performance of fabric surface.

The instrument is also suitable for the performance verification of new products developed, quality control of production departments, product performance verification of third-party testing institutions, and the measurement of material performance by laboratories and quality and technical supervision departments.
