High-efficiency Filter Test Bench| Testing Equipment

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Introduction

The high-efficiency filter scanning test bench (referred to as the test bench) is designed and manufactured in accordance with the principles and requirements of the European standard EN1822-4 and in reference to relevant standards. Under the determined air volume conditions, test the efficiency and resistance of the filter and use the automatic scanning method to detect leaks in the filter. The location of the leak point can also be repeatedly detected manually. The foundation and core of the test bench is the particle counter. The aerosol medium used in the test bench is liquid aerosol (DEHS), with a particle size of ≥0.3μm(0.1μm can be selected according to customer requirements).

Reference Standard

EN 1822:2009 High efficiency air filters

GB/T 13554-2020 "High Efficiency Air Filters"

GBIT 6165-2021 "Test Methods for Performance of High Efficiency Air Filters - Efficiency and Resistance"

IEST-RP-CC007.2 ULPA filter test

1S High-efficiency air filter

Technical Parameters

Upper computer Adopt an advanced configuration software system
Lower computer Siemens PLC
Counter Five high-flow laser particle counters
Counter sampling flow 28.3 L/min + 5%
Counter particle size range 0.3μm, 0.5μm, 1.0μm, 3.0μm, 5.0μm, 10.0μm
Aerosol DEHS
Diluter 0.111111111
Tested filter Flat plate type high-efficiency filter
Filter size range 300mmx300mm-1200mmx1200mm
Filter thickness range 50mm-300mm
The efficiency range of the test 85%-99.9995%
Air volume range 500m³/h~3500m³/h
Resistance range 0~1000pa
Measure the uniformity of wind speed at the cross-section 10% or less
Scanning head speed ≤5cm/s(adjustable)
Supply voltage Three-phase four-wire :AC380V±5% Frequency: 50HZ
Power consumption 10kW
Test bench dimensions 8600x4000x2000mm(length x width x height)(estimated)
Gas source (Oil-free, water-free):≥0.4MPa
