Taber Abrasion Tester (Double-Head) | Testing Equipment
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Standards
DIN Standards: DIN 53754 (plastics), DIN 53109 (paper/board), DIN 52347 (glass/plastics)
ASTM Standards: ASTM D1044 (transparent plastics), ASTM D3884 (textiles), ASTM D4060 (coatings)
ISO Standard: ISO 5470 (rubber/plastics-coated fabrics)
TAPPI Standard: TAPPI T476 (paper/paperboard abrasion)
Product Advantages
Dual-Testing Efficiency: Simultaneous testing on two independent stations doubles productivity, ideal for high-throughput laboratories.
Wide Applicability: Suitable for luggage, carpets, automotive interiors, textiles, coatings, metals, electronics, and more.
Precision Engineering: Adjustable pressure settings (125–1250g per wheel) and digital speed control (30–75 RPM) ensure standardized testing.
User-Centric Design: Intuitive LCD interface with preset cycle counts (1–999.999 revolutions) and vacuum debris removal for accurate results.
Versatile Compliance: Meets ASTM’s dual-head method requirements and global industry standards.
Quiet Operation: Branded silent motor minimizes noise during extended testing sessions.
Product Features
Dual Testing Stations: Independent control of two abrasion heads for parallel testing or comparative analysis.
Digital Control Panel: Real-time speed display, adjustable RPM, and programmable cycle counters with automatic stop.
Adjustable Vacuum System: Height-customizable suction port adapts to material thickness, ensuring debris-free testing.
Modular Abrasion Wheels: Interchangeable wheels (e.g., CS-10. H-18) and sandpaper discs for material-specific wear simulation.
Precision Balancing: Rear-arm counterweights (250g, 500g, 750g, 1000g) enable ASTM-standard 125g pressure and beyond.
Sample Preparation Kit: Includes sample stickers, diamond polishers, and vacuum attachments for seamless workflow.
Technical Parameters
| Parameter | Specification |
|---|---|
| Rotational Speed | 30–75 RPM (digital adjustment) |
| Sample Diameter | 100 mm (per station) |
| Test Platform Diameter | 113 mm (per station) |
| Cycle Range | 1–999.999 revolutions (presettable) |
| Empty Arm Pressure | 250g (standard) |
| Weight Options | 250g, 500g, 750g, 1000g (included) |
| Wheel Pressure Range | 125g, 250g, 500g, 750g, 1000g, 1250g (per station) |
| Vacuum Arm Adjustment | Height-adjustable (per station) |
| Power Supply | 220V, 50Hz |
| Dimensions | 220 (W) × 380 (D) × 300 (H) mm |
| Net Weight | 20 kg |
