Leakage trace tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

TheLeakage Trace Testeris a precision diagnostic tool designed to visually identify and analyze fluid/gas leakage paths in sealed systems. It employs non-destructive testing methods, combining thermal imaging and dye penetration technology to highlight leaks with fluorescent or colored markers.

Type: Portable handheld device

Detection Sensitivity: 0.1μm micro-leaks

Working Modes: Fluorescent dye tracing / Smoke injection visualization

Power Supply: Rechargeable Li-ion battery (8h continuous operation)

Applications

Automotive:Fuel injector testing, brake system diagnostics

Industrial:Pipeline joint inspection, HVAC system leak mapping

Aerospace:Hydraulic fitting validation under pressure

Medical:Sterile seal integrity verification

Standards

ISO 10110-3:Optics and optical instruments - Preparation of drawings for optical elements and systems - Part 3: Material imperfections - Bubbles and inclusions

ASTM E1137::Standard Specification for Industrial Platinum Resistance Thermometers (PRTs)

CE EN 61010-1:Safety requirements for electrical equipment for measurement, control, and laboratory use - Part 1: General requirements

Features

Dual Detection Modes:

Fluorescent Mode:Requires UV light for trace visualization

Smoke Mode:Generates visible vapor for pressurized systems

Smart Indicator System:

LED severity scale (green/yellow/red)

Audio alarm with dB level adjustment

Ergonomic Design:

Anti-slip rubberized grip

Rotatable 360° detection head

IP Rating: IP54 dust/water resistance

Parameters

ParameterSpecifications
Detection Accuracy ±0.5mm leak path resolution
Working Temperature -20°C to 150°C
Illumination Range UV-A 365nm wavelength (1000μW/cm² intensity)
Smoke Generation Non-toxic mineral oil-based vapor (OSHA compliant)
Dimensions 280×120×65mm (L×W×H)
