Automotive Floor Mat Abrasion Tester，Automotive interior carpet abrasion tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Automotive Floor Mat Abrasion Tester is designed for evaluating the abrasion resistance of automotive floor mats and textile floor coverings. The tester simulates the repetitive friction generated by a driver’s heel during vehicle operation and quantitatively assesses material wear behavior under defined load and friction angle conditions.
The equipment is compact, mechanically stable, and easy to operate, making it suitable for routine testing in product development, quality control, and durability verification.
Application
The tester is used for abrasion performance evaluation of automotive interior floor coverings, including but not limited to:
(1) Textile automotive floor mats (tufted carpets, woven or nonwoven carpets)
(2) Rubber, polyurethane, and composite floor mats
(3) Passenger car and commercial vehicle floor coverings
(4) Comparative abrasion behavior of different materials and structures
(5) Development and validation of wear-resistant interior materials
(6) Automotive OEMs, component suppliers, interior material laboratories, and quality control departments
Standards
The tester is designed according to the following standard:
(1) PV 3934 – Abrasion testing of automotive floor coverings and floor mats
Customer-specific or internal standards can be implemented upon request.
Parameters
| Item | Specification |
|---|---|
| Overall dimensions | 560 × 520 × 430 mm |
| Weight | Approx. 65 kg |
| Test range | Adjustable friction distance / cycles, up to 100 cycles per unit (configurable) |
| Abrasion load | Adjustable via weights and crank mechanism |
| Friction angle | Adjustable, simulating heel contact angle |
| Power supply | Standard AC power or customer-specified configuration |
Features
(1) Realistic abrasion simulation through adjustable load and friction angle
(2) Stable mechanical structure ensuring high repeatability of test results
(3) Simple mechanical adjustment using crank and locking nut mechanisms
(4) Safety protection with guard cover and Siemens safety switch
(5) Suitable for a wide range of floor mat materials, thicknesses, and sizes
Test Procedures
(1) Prepare and cut the floor mat sample with a flat backing surface
(2) Fix the sample on the test platform
(3) Adjust heel penetration depth to 5 ± 1 mm using the slotted nut
(4) Set abrasion load, friction angle, and number of cycles
(5) Start the test and allow the abrasion head to perform reciprocating motion
(6) Stop the test after completion and record wear condition
Maintenance Information
(1) Regularly inspect abrasion head and replace if excessive wear is observed
(2) Keep mechanical transmission parts clean and properly lubricated
(3) Check safety switch and protective cover before operation
(4) Store the equipment in a dry environment to prevent corrosion
