BBA Steady-State Solar Simulator
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The BBA Steady-State Solar Simulator is applicable in multiple scenarios:
Factory performance testing and certification of PV modules
R&D evaluation of PV module maximum power and electrical performance
Photovoltaic module light-induced degradation and hotspot durability testing
Temperature coefficient and low-irradiance performance measurements
Type testing and laboratory simulation of PV module aging
Climate environment laboratories simulating controlled light conditions
Standards
The simulator complies with key international standards:
(1) GB/T 6495.3 – Solar Radiation – Measurement of Spectral Irradiance Distribution
(2) IEC 61215 – Crystalline Silicon Terrestrial Photovoltaic Modules – Design Qualification and Type Approval
(3) IEC 61646 – Thin-Film Photovoltaic Modules – Design Qualification
(4) IEC 60904-6 – Photovoltaic Devices – Procedures for Using Reference Cells and Simulators
Parameters
| Item | Technical Specification |
|---|---|
| Effective Test Area | 2.0 × 1.0 m |
| Simulator Class | BBA |
| Spectral Match | Class B |
| Irradiance Uniformity | Class B |
| Instantaneous Instability | Class A |
| Light Source Type | Metal halide lamp |
| Measurable Parameters | NOCT, STC, Hot Spot |
| Light Source Lifetime | Single lamp ~1000 hours, 1 spare set provided |
| Illumination Direction | Top-down, vertical incidence on module |
| Consumables Lifetime | Light source and filters for 2000 hours of use |
| Light Intensity Range | 800 – 1000 W/m², continuously adjustable |
| Low Irradiance Testing | Down to 200 W/m² |
| Operating Temperature | +15°C to +30°C |
| Power Supply | 380V, 50Hz, ≤150A |
| Software Features | Simplified/Traditional Chinese, English; data storage, query, export/print; report output to Word, Excel, PDF, JPG |
| Supporting Equipment | Dedicated computer for software operation |
