Multi-Purpose Friction and Wear Tester
Get a quote：
Email：info@qinsun-lab。com
Web: qinsun-lab.com
The Multi-Purpose Friction and Wear Tester is a laboratory testing system designed to evaluate friction behavior and wear performance of engineering materials under controlled contact, load, speed, and temperature conditions. You can use this instrument to conduct standardized and comparative tribological testing by simulating rolling, sliding, and mixed lubrication conditions commonly encountered in industrial applications.
Standards
GB/T 3960 — Method for Friction Testing of Metals
GB/T 3961 — Method for Wear Performance Testing of Materials
ASTM G77 — Block-on-Ring Wear Testing Method
ASTM G99 — Ball-on-Disk Wear Testing Method
ISO 7148-2 — Plain Bearings and Lubrication Friction Testing
DIN 50324 — Standard Methods for Friction and Wear Testing
Parameters
| Item | Specification |
|---|---|
| Contact geometry | Crossed cylinder / Ball-on-cylinder / Block-on-ring / Double roller |
| Center distance | 60 mm |
| Roller diameter | 60 mm |
| Sliding specimen | 12.7 mm ball, roller, or block |
| Speed range | 30 – 850 rpm |
| Maximum sliding speed | 4.7 m/s |
| Slip ratio settings | 0.00%, 3.33%, 5.00%, 10.00%, 15.00%, 20.00% |
| Maximum friction force | 130 N |
| Friction force measurement | Strain gauge sensor |
| Load range | 50 – 750 N |
| Load actuator | Pneumatic cylinder |
| Load control | Precision pressure regulator |
| Load measurement | Pressure sensor |
| Test chamber temperature | Ambient to 150 °C |
| Heating power | 150 W |
| Temperature sensor | Type K thermocouple |
| Motor | Brushless DC servo motor, 200 W |
| Control mode | Speed, temperature, and test duration automatic; load manual |
| Measured parameters | Speed, load, friction force, temperature, revolutions, time, sliding distance, friction coefficient |
| Software interface | USB communication module |
| Power supply | 220/240 V, single phase, 50 Hz, 1.2 kW or 110/120 V, single phase, 60 Hz, 1.2 kW |
