Multi-Purpose Friction and Wear Tester

Get a quote:

Email:info@qinsun-lab。com

Web: qinsun-lab.com

The Multi-Purpose Friction and Wear Tester is a laboratory testing system designed to evaluate friction behavior and wear performance of engineering materials under controlled contact, load, speed, and temperature conditions. You can use this instrument to conduct standardized and comparative tribological testing by simulating rolling, sliding, and mixed lubrication conditions commonly encountered in industrial applications.

Standards

GB/T 3960 — Method for Friction Testing of Metals

GB/T 3961 — Method for Wear Performance Testing of Materials

ASTM G77 — Block-on-Ring Wear Testing Method

ASTM G99 — Ball-on-Disk Wear Testing Method

ISO 7148-2 — Plain Bearings and Lubrication Friction Testing

DIN 50324 — Standard Methods for Friction and Wear Testing

Parameters

ItemSpecification
Contact geometry Crossed cylinder / Ball-on-cylinder / Block-on-ring / Double roller
Center distance 60 mm
Roller diameter 60 mm
Sliding specimen 12.7 mm ball, roller, or block
Speed range 30 – 850 rpm
Maximum sliding speed 4.7 m/s
Slip ratio settings 0.00%, 3.33%, 5.00%, 10.00%, 15.00%, 20.00%
Maximum friction force 130 N
Friction force measurement Strain gauge sensor
Load range 50 – 750 N
Load actuator Pneumatic cylinder
Load control Precision pressure regulator
Load measurement Pressure sensor
Test chamber temperature Ambient to 150 °C
Heating power 150 W
Temperature sensor Type K thermocouple
Motor Brushless DC servo motor, 200 W
Control mode Speed, temperature, and test duration automatic; load manual
Measured parameters Speed, load, friction force, temperature, revolutions, time, sliding distance, friction coefficient
Software interface USB communication module
Power supply 220/240 V, single phase, 50 Hz, 1.2 kW or 110/120 V, single phase, 60 Hz, 1.2 kW
