Floor Scrubber Air Performance Testing Equipment
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
TheFloor Scrubber Air Performance Testing Equipmentis designed for comprehensive evaluation of vacuum cleaners with integrated scrubbing and suction functions. You use this equipment to measure and record critical parameters such as voltage, current, input power, power factor, suction power, airflow, vacuum level, and overall efficiency. The system employs an industrial control computer with a 17-inch monitor to automatically calculate and record all test data. Results can be exported via USB or printed for reporting purposes. The equipment is compliant with European and American standards, providing accurate, repeatable, and reliable performance testing.
Standards
IEC 60312:2010 – Rotodynamic Vacuum Cleaners – Methods for Measuring the Performance
F431-21 – American Standard for Vacuum Cleaner Performance Testing (Airflow, Suction, and Power)
F558-17 – American Standard for Vacuum Cleaner Energy Efficiency and Flow Measurement
GB/T 20291.1-2014 – Performance Test Methods for Vacuum Cleaners
ISO 29463-3:2011 – HEPA and ULPA Filters for Airborne Particle Removal
Features
-
Supportsboth European and American testing standards
-
Real-time monitoring ofvoltage, current, power, suction, and airflow
-
High accuracy withservo-driven flow measurement and vacuum detection
-
Automatic data acquisition, calculation, andUSB export or print output
-
Single-station design allowsefficient space utilization
-
Suitable for testingfloor scrubbers and hybrid vacuum-cleaner units
Technical Parameters
| Item | Specification |
|---|---|
| Test Stations | Single station |
| Pressure Chamber Dimensions | Euro standard: 500×500×500 mm; US standard: 457.2×457.2×254 mm |
| Test Modes | Euro standard, US standard |
| Drive Motor | Servo motor |
| Flow Meter | Range: 0.5–5 m³/min; Accuracy: ±1% |
| Vacuum Gauge | Range: -50–0 Kpa; Accuracy: ±1% |
| Orifice Plate Sizes (US & Euro standard) | 63.5, 57.2, 50.8, 44.5, 38.1, 34.9, 31.7, 28.6, 25.4, 22.2, 19.0, 15.8, 12.7, 9.5, 6.3 mm |
| Power Supply & Current Detection | AC: 0–250V; DC: 0–60V; Current detection range: 0–30A |
| Equipment Power | 220V, 2.5KW |
| Equipment Dimensions | 1850×1150×1750 mm |
