Automotive & Motorcycle Control Cable (Flexible Shaft) Fatigue Tester
Get a quote：
Web: qinsun-lab.com
Email：serving@qinsun-lab。com
The Automotive & Motorcycle Control Cable (Flexible Shaft) Fatigue Tester is designed to evaluate the durability and fatigue performance of automotive and motorcycle control cables. By simulating repeated force and reciprocating motion experienced during actual use, it quantitatively assesses structural stability, service life, and reliability under defined loads and cycles, providing reliable data for design validation and quality control.
Application
This tester is applicable to a wide range of vehicle control cables and flexible shaft assemblies, including but not limited to:
(1) Automotive throttle cables
(2) Automotive clutch cables
(3) Automotive brake cables
(4) Automotive gear shift cables
(5) Automotive parking brake cables
(6) Motorcycle throttle cables
(7) Motorcycle clutch cables
(8) Motorcycle brake cables
(9) Bowden cables and flexible shaft assemblies
(10) Control cables for electric vehicles, light vehicles, and specialty vehicles
Suitable for: automotive manufacturers, motorcycle production facilities, cable/component manufacturers, third-party testing labs, and research institutions.
Standards
(1) QC/T 29101-92 — Automotive Cable Assemblies
(2) QC/T 228.10-1997 — Motorcycle and Moped Control Cable Test Method
(3) SAE J193 — Automotive Control Cable Reference Test Method
(4) ISO 6722 — Reference Principles for Cable and Component Durability Testing
Parameters
| Item | Technical Specification |
|---|---|
| Maximum Cable Load | 5000 N |
| Reciprocating Stroke | ±50 mm |
| Reciprocating Frequency | 30 / 60 cycles per minute |
| Test Cycle Range | 0–999,999 cycles |
| Test Cycle Accuracy | ±0.5% |
| Load Application | Pulley mechanism + standard weight + spring |
| Motion Conversion | Crank-slider mechanism |
| Drive | Dual-speed motor |
| Power Supply | AC 380V ±10% (3-phase) / AC 220V ±10% (single-phase) |
| Control | Electro-mechanical |
| Display | Digital counter display |
Features
(1) Standards-compliant design ensures reliable, repeatable test results.
(2) Wide load capacity up to 5000 N for most automotive and motorcycle cables.
(3) Stable reciprocating motion with crank-slider mechanism simulates real operating conditions.
(4) Accurate cycle counting with magnetic-electrical sensor and clear digital display.
(5) Adjustable stroke and frequency for different cable types and standards.
(6) Robust structure suitable for long-term continuous fatigue testing.
