Steam jet durability testing machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Steam Jet Test Chamber is designed to evaluate the durability and performance of materials and components under high-pressure steam exposure. All parts in contact with the medium are rust-resistant and suitable for operation with deionized water. The system features a ceramic plunger pump with direct-drive motor, high safety, low wear, and an integrated safety valve. You can precisely control the steam injection duration, from 1 second up to 9 minutes, and adjust the pressure externally depending on nozzle specifications.
Standards
The Steam Jet Test Chamber complies with a broad set of international automotive and industrial standards, including:
DIN EN 16925:2014-06 – German and European standards for environmental and mechanical performance testing of coatings and materials
DBL 5416 – German DBL internal engineering standard for component durability and functionality
Ford BO 160-04 – Ford engineering standard for functional and reliability testing of components
GM 9531 – General Motors global engineering standard for material and component durability
Volvo STD 423-0015 – Volvo Group internal standard for functional and durability testing of components
VW PV 1503 – Volkswagen Group specification for material and functional performance
BMW AA-0136 – BMW Group engineering standard for system component functionality and durability
Renault D 252018 – Renault engineering standard for component performance and testing
PSA D 255376 – PSA Group engineering standard for component functionality and durability
MAN M 3022 – MAN Commercial Vehicles internal standard for component performance and durability
Parameters
| Parameter | Details |
|---|---|
| Flow Rate | 14.8 L/min |
| Working Pressure (P) | 30 – 140 bar (adjustable via external pressure valve) |
| Motor (N) | 6.5 kW, 400 V |
| Plug | 32 A, 5-pole |
| Water Supply | 2 – 3 bar, 15°C |
| Nozzle Distance | 0 – 450 mm |
| Test Angles | 90°, 45°, 30° ±2° |
| Other Components | Door with inspection glass, exhaust Ø 102 mm, connectors, discharge port with dirt filter |
| Base Frame | Stainless steel with enclosure and four guide rails |
| Sterilization/Water Replacement | Automatic weekly cycle: water heated to 68°C, sprayed through nozzles; stops at 70°C; manual water replacement possible. Cooling to working temperature required after sterilization, can be accelerated with cold water addition |
| Door Locking | Electromagnetic locking during pump operation; door cannot be opened while pump is running |
| Heating Vessel | 9.0 kW, max temperature 80°C ±2°C, digital display, preheat time 1 hour |
Accessories
Horizontal sliding unit
Exhaust fan
Laser pointer
Flow meter
Volume-measuring testing equipment (in liters)
Clamping device
