Filter Dynamic Cycling Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Filter element dynamic cycling test bench is mainly used to test the chemical element precipitation characteristics of filter element under long-term dynamic cycling. It adopts touch screen operation mode, combined with PLC control, according to the setting line, and can analyze and judge the abnormal state in the test process and send out alarm information. Manual interval sampling and analysis.
Applications
Mainly used for performance testing of filter elements (such as hydraulic oil filter elements, fluid filtration filter elements, etc.):
1. Evaluating the chemical element precipitation characteristics of filter elements under long-term dynamic cyclic conditions;
2. Testing the durability of filter elements under repeated dynamic stress cycles and predicting their fatigue life;
3. Assisting in the quality inspection, performance verification, and research and development improvement of filter elements.
Standards
(1) ISO 23840 — Hydraulic fluid power — Filters — Evaluation of filter performance using multipass test.
(2) JB/T 7857 — Performance test of hydraulic filter elements.
(3) ISO 2942 — Hydraulic fluid power — Filter elements — Verification of fabrication integrity.
(4) GB/T 14041.1-1993 — Hydraulic filter elements — Structural integrity test methods.
(5) ISO 4003 — Permeable sintered metal materials — Determination of fluid permeability.
(6) GB/T 5249-1985 — Permeable sintered metal materials — Bubble test method for pore size determination.
(7) QC/T 794-2007 — Filter paper for internal combustion engines.
Features
1. Specialized Functions: It can test the chemical element precipitation characteristics of filter elements under long-term dynamic cycling, and simultaneously evaluate the durability of filter elements under repeated dynamic stress cycling and predict fatigue life.
2. Intelligent Control: Utilizing touchscreen operation + PLC control, it can automatically identify and alarm abnormal states during the test process, offering convenient operation and stable performance.
3. Comprehensive System Configuration: Includes a circulation system (variable frequency pump set, temperature control/stirring components), a real-time temperature control system (temperature control accuracy ±2℃), and an industrial-grade electrical system, with clearly defined functional modules.
4. Lightweight Structure: The test bench frame is made of high-strength industrial aluminum profiles, combining the advantages of light weight, high strength, and aesthetic appearance.
Technical Parameters
| No. | Technical Indicators | Specifications |
|---|---|---|
| 1 | Test medium | Water containing boron, and containing lithium hydroxide |
| 2 | Test flow | 2-10 m³/h (working point: 5.7) |
| 3 | Rated pressure | 0.8 MPa |
| 4 | Test cartridge differential pressure | 0.4 MPa |
| 5 | Maximum working temperature | 80°C |
| 6 | Test tank volume | 2000L |
| 7 | Maximum cartridge size | 2.5 inches × 60cm (diameter × height cm), with a set of equipment |
| 8 | Test bench power | 22kW |
| 9 | Test bench power supply | Three-phase five-wire AC380V / 50Hz |
