Filter media test rig according to ISO 16890
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Filter Media Test Rig is designed for characterization of filter media and small-scale filter elements according to various standards. It measures key parameters such as differential pressure, gravimetric separation efficiency, fractional efficiency, and dust loading capacity. Reliable and repeatable testing is critical for development, optimization, and quality assurance of filter media.
Application
The system is applicable for:
(1) Cleanable Filter Media: Testing in accordance with VDI 3926-2.
(2) Air Filter Testing:
- General air filters (ISO 16890, EN 779, ASHRAE 52.2)
- High-efficiency filters (EPA, HEPA, ULPA, ISO 29463)
- Cabin air filters (DIN 71460-1 / ISO/TS 11155-1)
- Engine intake filters (ISO 5011)
(3) Filter Media Development and Optimization: Laboratory and R&D testing.
(4) Quality Assurance: In-line production monitoring and final inspection.
(5) Flat Media Quality Control: Pre-processing or post-production inspection of planar media.
Standards
The system can execute and complies with:
(1) ISO 16890 – Air filter classification standard.
(2) ISO 29463 – High-efficiency filter performance standard (EPA/HEPA/ULPA).
(3) ISO 5011 – Engine and industrial machinery air filter testing.
(4) ISO/TS 11155-1 – Automotive air filter performance testing.
(5) ISO 11057 – Clean air filter media performance testing.
(6) VDI 3926-2 – Characterization of cleanable filter media.
(7) EN 779 – High-efficiency air filter testing.
(8) ASHRAE 52.2 – Air filter performance standard.
(9) DIN 71460-1 – Automotive intake filter performance testing.
Parameters
| Parameter | Unit | Value |
|---|---|---|
| Test Flow Rate | m³/h | 0.4 … 40 or 2 … 64 |
| Test Aerosol | – | Custom (DEHS, paraffin oil, NaCl, PSL, etc.) |
| Test Specimen Dimensions | mm | Diameter ≤ 150 |
| Operating Gas/Air Supply | – | Laboratory air; compressed air 6 bar |
| Power Supply | – | 400 VAC, 16 A |
| Ambient Temperature | °C | 0 … 50 |
| Relative Humidity | % | 0 … 100 |
| System Dimensions (W × H × D) | mm | 2100 × 1400 × 850 |
| Weight | kg | approx. 300 |
