Yarn Twist Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Yarn Twist Tester is a precision instrument designed to measure the twist level and twist direction of yarns. It is widely used in textile testing laboratories and production quality control to evaluate yarn structure and performance, ensuring compliance with relevant testing standards.
Standard
FZ/T 70001-2003: Textile – Determination of Skein Length
FZ/T 71004-2003: Wool Knitted Fabrics – Test Methods for Physical Properties
GB/T 4743 Textiles-Yarn from packages-Determination of linear density (mass per unit length) by the skein method
GB/T 14343Testing method for linear density of synthetic filament yarns
GB/T 6838Testing method for sewing threads
ISO 2060Textiles-Yarn from packages-Determination of linear density (mass per unit length)-Skein method
ASTM D1907Standard Test Method for Linear Density of Yarn (Yarn Number) by the Skein Method
Application
Textile Manufacturing: Ensures skein length meets specifications for wool, blended yarns, and knitted fabrics.
Quality Inspection: Used by labs and certification bodies to validate product standards.
R&D: Supports material innovation by assessing yarn twist and structural integrity.
Product Advantages
High Precision: Manual control with 0.1 cm scale accuracy for reliable length measurement.
Versatile Loading: Adjustable counterweights (300g/500g/1500g) suit diverse yarn densities.
Durable Construction: SUS304 stainless steel weights resist corrosion.
Easy Operation: Blade-shaped hanging plates ensure even sample spreading.
Compact Design: Portable size (350×600×150 mm) and 35 kg weight for lab flexibility.
Cost-Effective: Manual control reduces maintenance vs. automated systems.
Product Features
Blade-Shaped Hanging Plates: Secure upper/lower sample ends for stable tension.
Lever-Type Pressure: Applies consistent force via 19mm diameter rollers.
Adjustable Counterweights: 2.4kg/3.0kg/6.0kg options (incl. lower plate deadweight).
Roller System: Upper/lower rollers (19mmØ) ensure smooth yarn unwind.
Length Calculation: FormulaA=(L-πd)/2(A: Roller center distance; L: Skein length; d: Roller diameter).
Real-Time Reading: Scale records deformation within 30 seconds for quick validation.
Technical Parameters
| Parameter | Specification |
|---|---|
| Control Mode | Manual Operation |
| Max. Measuring Length | 1800 mm |
| Loading Range | 300 g / 500 g / 1500 g (Adjustable) |
| Roller Diameter | Upper/Lower: 19 mm |
| Pressure Type | Lever-Type Mechanism |
| Counterweight Material | SUS304 Stainless Steel |
| Power Supply | AC 220V ±10%, 50Hz |
| Dimensions (L×W×H) | 350 mm × 600 mm × 150 mm |
| Net Weight | 35 kg |
