Fully automatic dual-plate guarded hot plate thermal conductivity tester
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Application
This testeris suitable for testing the thermal conductivity of:
Plastics, rubber, glass, and fiber boards
Polystyrene foam (EPS), extruded polystyrene foam (XPS), polyurethane rigid foam
Foamed concrete, hollow glass, wood boards
Various insulation materials
Granular, loose, or soft materials (with optional fixtures)
Typical applications include:
Quality inspection of insulation and construction materials
R&D in thermal performance of polymer and foam materials
Academic research in thermal properties of solid and granular samples
Industrial production control for plastics, foams, and composite boards
Standards
The instrument complies with the following international and national standards:
GB/T 10294-2008 – Determination of Steady-State Thermal Resistance and Related Properties of Insulating Materials
GB/T 3399-1982 – Test Method of Thermal Conductivity for Plastics by Guarded Hot Plate Method
GB/T 10801.1-2002 – Measurement of Thermal Conductivity for Polyurethane Rigid Foam in Thermal Insulation
GB/T 10801.2-2002 – Measurement of Thermal Conductivity for Extruded Polystyrene Foam (XPS)
GB/T 3139-2005 – Test Method of Thermal Conductivity for Fiber Reinforced Plastics
GB/T 17794-2008 – Flexible Foam Rubber and Plastic Thermal Insulation Products
Parameters
| Item | Specification |
|---|---|
| Thermal conductivity range | 0.001–3.000 W/m·K |
| Measurement accuracy | ±2% |
| Repeatability | ±1% |
| Hot plate temperature range | Room temperature–150 °C (standard); optional up to 300 °C |
| Hot plate resolution | 0.01 °C |
| Cold plate temperature range | 0–60 °C (standard); optional -5–60 °C |
| Cold plate resolution | 0.01 °C |
| Sample thickness | 0–100 mm; resolution 0.001 mm; automatic measurement |
| Applied pressure | 0–500 N; resolution 0.1 N |
| Sample size | 300×300×(5–50) mm (standard); custom sizes available |
| Automation | Fully computer-controlled testing and data processing |
| Test duration | 60 minutes |
| Power supply | 220 V / 50 Hz; 500 W |
Accessories
Main instrument
Analysis software (Chinese & English versions)
HX-1005 precision low-temperature constant temperature water bath (0.01 °C accuracy)
Desktop computer (user-selected)
Calibration reference sample
