Laboratory Car Wash Simulator ISO 20566

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Laboratory Car Wash Simulator is suitable for a wide range of automotive material and component testing:

Automotive Coatings: Evaluate wash durability of organic coatings on vehicle bodies and parts.

Clear and Colored Paints: Assess scratch resistance of single-layer and multilayer coating systems.

Paint Protection Films (PPF): Test wash durability and appearance retention.

Plastic Exterior Components: Evaluate surface wear resistance of bumpers, trims, and covers.

Functional Coatings: Assess coatings applied on metal or plastic substrates.

R&D and Quality Control: Simulate car wash tunnel conditions to validate and verify surface materials.

Typical test products include automotive panels, bumpers, trims, protective films, and functional coated parts.

Standards

The simulator supports compliance with the following international standards:

ISO 20566:2021 – Paints and varnishes – Laboratory-scale car wash machine testing.

ISO 13076 – Visual assessment of coating surface appearance.

ISO 2813 – Measurement of gloss of coatings.

ISO 13803 – Measurement of haze of coatings.

ISO 7724 – Color measurement and color difference evaluation of coatings.

Parameters

ParameterDetails
Dimensions W3100 × D950 × H1800 mm
Weight ~450 kg
Main Body Material SUS 304 stainless steel
Test Environment Temperature 23 ± 3 ℃
Test Environment Humidity 50 ± 5 %RH
Test Medium Clean water + silicon dioxide
Medium Temperature 15 – 30 ℃
Brush Direction Clockwise / Counterclockwise
Brush Speed 70 – 127 ± 5 rpm
Brush Cycles 1 – 999 cycles
Wash Liquid Capacity 80 L
Sample Thickness 1.5 – 3.5 mm
Sample Size 155 × 305 mm (up to 4 pieces) or 310 × 610 mm (1 piece)
Platform Speed 5.0 ± 0.2 m/min
Spray Flow Rate 2.2 ± 0.2 L/min
Spray Pressure 300 ± 50 kPa
Power Supply AC 220 V, 2.2 kW, 50 Hz

Features

Realistic Car Wash Simulation: Rotating brushes, reciprocating sample movement, and synthetic soiling spray replicate actual automatic car wash conditions.

Standard-Compliant Design: Brush spacing, rotation speed, pressure, and platform motion are adjustable according to ISO 20566:2021.

Replaceable Brush Structure: Brushes are removable for easy maintenance and replacement, ensuring consistent testing.

High Stability Platform Drive: Servo motor-driven platform with dual limit protection ensures smooth and reliable operation.

Uniform Cleaning Medium Circulation: Built-in agitation system ensures consistent medium composition for repeatable results.
