Laboratory fully automatic scratch hardness testing machine
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Standards
(1) ISO 1518 – Paints and Varnishes – Determination of Scratch Resistance
(2) BS 3900 – Paints Testing Methods (UK Standard Series)
(3) ASTM D5178 – Test Method for Scratch Resistance of Coatings Using a Linear Scratch Device
(4) ASTM D2197 – Test Method for Resistance of Organic Coatings to Scratching
Parameters
| Parameter | Specification |
|---|---|
| Stylus Type | Spherical steel stylus |
| Maximum Test Load | Configurable according to standard and sample requirements |
| Test Sample | Single-layer or multi-layer coated panels |
| Operation Mode | Fully automatic |
| Control Interface | Touchscreen with multilingual support (Chinese/English) |
| Workbench | Level detection system integrated |
| Power Supply | AC 220V / 50Hz |
| Machine Type | Desktop, low noise, stable operation |
Features
Panel made of special aluminum with metallic buttons, durable and responsive.
Touchscreen interface for intuitive, easy operation.
Dedicated sample clamps for direct and stable positioning.
Conductive substrate indicates whether the coating is penetrated, with an alarm function for penetration detection.
Multilingual interface (Chinese/English) with intelligent control.
Precision guide rails used for core transmission mechanism for accurate movement.
Electrostatic spray finish for durable surface protection.
Integrated horizontal level detection ensures accurate positioning.
Desktop design with stable operation and low noise.
Accessories
(1) Spherical steel stylus (replaceable)
(2) Sample clamps and fixture set
(3) Calibration and load verification kit
(4) User manual and operation guide
Test Procedures
Sample Installation
Place the coated panel in the sample clamps on the workstation. Ensure proper alignment and level using the built-in horizontal detection system.
Parameter Setup
Set the test load, number of cycles, and stylus path on the touchscreen interface.
Test Execution
Start the automatic test sequence.
The stylus applies a controlled load to the sample, moving along the programmed path to test scratch resistance.
The system automatically detects penetration and triggers an alarm if the coating is breached.
Result Recording
The maximum load at which the coating remains intact is recorded.
Data can be exported or analyzed for quality control and compliance assessment.
