Spring Torsion Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The spring torsion testing machine is suitable for measuring the torsion angle and torsion torque of various large springs. With appropriate attachments, it can also perform torsional tests on parts and components. This machine complies with the standards JB/T 9370-1999 and JJG 269-2006 for torsion testing machines and material testing methods. Tests can also be conducted according to national and international standards such as ISO, JIS, ASTM, and DIN, providing reliable data. It is ideal for use in industrial and mining enterprises, technical supervision departments, commodity inspection arbitration, research institutes, universities, and quality inspection units.
Technical Parameters
| Parameter | Specification |
|---|---|
| Maximum test torque (N·m) | 10. 20. 50. 100. 200 |
| Minimum readable torque (N·m) | 0.001. 0.01. 0.1 |
| Minimum readable angle | 0.10° |
| Relative error of torque indication | ≤ ±1% |
| Relative zero error of torque indication | ≤ ±0.1% |
| Effective testing space of the machine | 160 mm |
| Coaxiality of fixture centerline | ≤ φ1 mm |
| Control system | PLC |
| Loading method | Automatic loading |
| Safety device | Compliant with JB/T 7796-1995 |
| Power supply | AC 220 V, 50 Hz |
Main Functions
(1)Digital display of torsion torque and angle
(2)LCD screen with Chinese-language menu operation
(3)Peak value hold function
(4)Overload protection function
(5)Stiffness calculation function
(6)Result printing function
(7)Data query function
(8)Automatic loading, freely selectable clockwise or counterclockwise rotation, simple operation, fast detection speed, and convenient clamping
