Smoke Detector Test Tunnel | ASTM ISO Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Smoke Fire Detector Threshold Test Chamber is suitable for:
Threshold verification of point-type smoke fire detectors.
Repeatability, orientation, and airflow testing in laboratory or production environments.
Industrial and residential smoke detector production quality control.
Specific Testing Equipment:
Point-type smoke detectors for home and industrial use
Alarm system components requiring threshold and response validation
Production testing lines for smoke detector quality assurance
Standards
The system conforms to the following national and international standards:
GB 4715-2005 – Technical Requirements and Test Methods for Point-Type Smoke Fire Detectors (China)
ISO 7240-7 – Fire Detection and Alarm Systems, Part 7: Smoke Detectors Using Scattered, Transmitted Light, or Ionization
EN 54-7 – Fire Detection and Fire Alarm Systems, Smoke Detectors
UL 268 – Standard for Smoke Detectors for Fire Protective Signaling Systems
EN54-7
EN54-29
EN14604
EN54-5
Parameters
| Unit | Specification |
|---|---|
| Temperature Range | 0–55 °C, adjustable via heating rods |
| Variable Frequency Fan | Supply voltage: 220 V; Max. static pressure: 330 Pa; Adjustable air volume: 0–275 m³/h |
| Airflow Requirement | 0.2 m/s |
| Optical Density Meter | Wavelength: 880–950 nm |
| Omega K-Type Sheathed Thermocouple | Diameter: 1.5 mm; Temperature measurement range: 0–1100 °C |
