Gas pulse testing machine

Get a quote：

Whats/App: +86 181 0160 0864

The Gas Pulse Testing Machine is a specialized system designed for evaluating automotive air-cooled and pressurized components under dynamic gas pressure conditions. You can use it to test turbocharger systems, intercoolers, and other pressurized air components with precise control. The machine provides automatic leak detection and shut-off for failed samples, while performing positive and negative pressure pulse testing to simulate real-world operational conditions.

Application

The Gas Pulse Testing Machine is suitable for a variety of automotive testing applications:

Turbocharger Components: Test air intake pipes, intercoolers, and hoses under dynamic pressure and temperature conditions.

Air-Cooled Systems: Evaluate radiators and heat exchangers subjected to pressurized air pulses.

Component Durability Testing: Conduct high-temperature pressure pulse tests to assess fatigue and long-term reliability.

Leak Detection: Automatically identify and shut down failed samples during testing.

Automotive R&D: Support material, design, and system optimization for air and turbocharged systems.

Typical test products include air intake pipes, intercoolers, turbocharger ducts, hoses, and other pressurized air system components.

Standards

The system supports compliance with major automotive engineering standards:

GMW16153. Version Oct. 2014 – GM global engineering standard for materials and component cleanliness/particle control.

TL VW60562‑2010‑06 – Volkswagen Group technical specification for system component performance and reliability.

Fiat 9.02132‑01 – Fiat engineering specification for component performance and testing requirements.

BMW 10403165‑03 – BMW group engineering specification for functional, material, and component testing.

Ford ESBB53‑6C646‑AA – Ford engineering standard for high-pressure intake pipe components.

LH 10354886‑000‑01 – LH internal standard for component durability and functional testing.

Parameters

Parameter Category	Details
Equipment Dimensions	4100 × 2400 × 2000 mm (W × H × D)
Environmental Chamber Dimensions	1500 × 1500 × 1000 mm (W × H × D)
Rated Power	35 kW
Test Medium	Air
Pressure Range	-0.5 … 5 bar
Pressure Frequency	> 0 … 2 Hz
Pressure Waveform	Trapezoidal, near Sine
Air Medium Temperature Range	+30 … +250°C
Environmental Chamber Temperature	+30 … +250°C
Test Channels	8
Motion Device Frequency	> 0 … 2 Hz
Motion Device Amplitude	max. ±30 mm

Features

Designed for testing automotive motor parts, particularly turbocharger pipelines.

Performs high-temperature pressure pulse testing under hot air conditions.

Equipped with a large environmental chamber for sample placement.

Pressure range from -0.5 to max. 5 bar.

Automatic leak detection and leak testing with fail-safe shutdown for defective samples.

Integrated robot for 3D motion simulation of test samples.

Windows-based control unit with real-time data recording.

Accessories

Environmental chamber with dual access doors

Linear and 3D robotic motion system

Pressure sensors and leak detection units

Air supply system with temperature and pressure control

Windows-based control and data acquisition software

Safety interlocks for failed samples

Sample mounting brackets for turbocharger components

Test Procedures

Ensure the test area is safe and allows full access to all test channels.

Connect the system to a 35 kW power supply.

Supply pressurized air to the chamber and confirm temperature control settings (+30 to +250°C).

Mount the turbocharger, intercooler, or air-cooled system component in the environmental chamber.

Start the Windows control system and set pressure pulse range, waveform, frequency, and amplitude.

Activate the robotic 3D motion system to simulate operational stresses.

Monitor air pressure, temperature, and leak detection sensors during testing.

Automatically shut down any failed samples.

Record all test data for compliance and durability analysis.

After testing, allow the system to cool before removing samples.
