Electric rolling wheel peeling testing machine
Electronic pressure roller testing machine (automatic pressure roller machine) specializing in intaglio printing process for the production of plastic film and cellophane decorative prints (including composite film prints) for the printing of the ink layer combined with the fastness of the test test test. Also used for vacuum coating, surface coating, composite and other related processes to form the surface layer of the adhesion of the state test test.
Applications
The electric rolling wheel peeling testing machine has a wide range of applications, not only limited to testing the adhesion of printing ink layers in gravure printing processes, but also covering the adhesion testing of various pressure-sensitive adhesive tapes and other adhesive materials. It is an indispensable testing device in quality inspection centers, packaging plants, and tape factories. Its high precision and efficiency enable enterprises and research institutions to understand material performance more quickly and accurately, thereby optimizing production processes and improving product quality and safety.
Standards
CNS 11888:Pressure-sensitive adhesive tapes — Test method for 180-degree peel adhesion strength
PSTC-8:180-Degree Peel Adhesion of Pressure-Sensitive Tape
Features
1. The quality, rubber thickness, and hardness of the pressure rollers are strictly designed according to national standards to ensure the accuracy and versatility of the test data.
2. The system adopts microcomputer control, equipped with a PVC operation panel and LCD display screen for easy data viewing and test operation.
3. Multiple test speeds are available to meet different standard requirements.
4. Automatic alarm prompts upon test completion to ensure user safety.
Technical Parameters
| Main Parameter | Specification |
|---|---|
| Rolling Speed | 10-600mm/min |
| Pressure Roller Load | 20 N±0.2 N |
| Number of Rolling Times | 3 (999 can be set) |
| Overall Dimension | 360mm(L)×230mm(B)×260mm(H) |
| Power Supply | 220VAC 50Hz / 120VAC 60Hz |
| Net Weight | 25 kg |
Accessoriess
1. Main Unit: Robust and durable, equipped with a high-precision pressure roller mechanism, capable of simulating pressure under real-world usage scenarios to ensure the reliability of test results.
2. Control System: Intelligent user interface allows users to easily set test parameters, such as pressure magnitude and pressure roller speed, enabling one-button start and automatic completion of the testing process.
3. Measurement System: Combining high-precision sensors and data processing software, it captures and records key data during the testing process in real time, providing strong support for result analysis.
Test Procedures
1. Preparation Stage
Select standard glass adhesive tape and adjust the pressure roller testing machine according to the established parameters.
2. Bonding Stage
Use the adhesive tape roller to firmly bond the glass adhesive tape to the ink-printed surface of the sample, ensuring no air bubbles are generated.
3. Conditioning Stage
Allow the bonded sample to stand under specified conditions for a period of time to allow the ink layer to fully bond with the substrate.
4. Peel Test
Start the testing machine and perform the peel test, observing and recording the peeling condition of the ink layer.
5. Result Analysis
Based on the peel test results, evaluate the adhesion strength of the printed ink layer to provide a basis for product quality control.
