Guide pin anchoring force tester

Guide pin anchoring force tester - Other test instrument - standard


Standards:

YY/T0880-2013 "Disposable Breast Positioning wire and Guide Needle"

Applications:

Product Information:

Product introduction

  The anchoring force test of the guide needle can ensure the anchoring effect of the mammary
positioning filament within the tissue and prevent the filament from shifting or falling out before
surgery. This is essential for stable positioning filaments to accurately locate and remove the tumor
during surgery.

Technical parameter
  1. Tensile force test range: 0——20N, error is not more than +1%, resolution 0.01N
  2. Test time: 1-999S, any choice, the error is not more than +0.5S
  3. Test speed: 10mm/min, 50mm/min, 100m/min
  4. Distance adjustment: 10mm——50mm adjustable
  5. Sensor: high-precision force value sensor (with hardware and software protection function)
  6. Fixture: high quality 304 stainless steel
  7. Force measuring mechanism: built-in
  8. Printer: on-board micro needle printer
  9. Data storage: USB disk can be imported into the computer storage
  10. Machine power: 70W
  11. Power supply: AC90V-240V/50Hz
