Drop ball rebound tester

Drop ball rebound tester - Other test instrument - standard


Product Information:

Main application scope and functions:

This machine is designed and manufactured according to GB/T6670-97. It is suitable for determining the falling ball resilience of soft polyurethane foams. The instrument calculates the maximum rebound height of the steel ball and the percentage of the falling height of the steel ball by the steel ball with a given diameter and quality falling freely on the foam sample at a specified height, and the rebound rate represents the resilience of the foam. The machine uses microprocessor to control, touch screen Chinese display, and can print test data. The machine has the characteristics of safety, reliability and high measurement accuracy.

Main technical parameters and accuracy:

Ball drop distance: 460+0.5%mm 500+0.5%mm (ASTM standard) dual purpose

Steel ball diameter: ¢16-0.05mm

Drop ball rebound rate accuracy: <1.5%

Test sample size: 100 mm ×100 mm × 50mm

Main configuration:

Host a set (including release mechanism, capture mechanism)

One set of control boxes
