Voltage Drop Tester for Automotive Wire Connectors
Все товары поставщика
Voltage Drop Tester for Automotive Wire Connectors - Other test instrument - standard
Product Information:
The voltage drop tester for automotive wire connectors is suitable for measuring the voltage drop at similar connection interfaces such as the pins of non - rewirable plugs and the leads of connecting plugs, so as to judge the quality of the connection interfaces. It can also be used for testing the contact voltage drop of terminals in connectors and wire harnesses. It complies with the ISO 8092.1 - .4 series of standards and relevant standards such as QC/T417.1 - 417.5 - 2001 for automotive wire harness connectors.
Technical Features:
This instrument features adjustable high - current output, micro - voltage testing, and digital tube display.
Main Parameters:
1. Input voltage: AC220V + 10%, 50Hz 2. Working current (DC): 0 - 100A (optional values including 5A, 10A, 20A, 50A, 100A, 200A, 500A, 1000A) and can be adjusted arbitrarily 3. Current output mode: Constant current 4. Voltage drop range: 0 - 20V (with three voltmeters of different accuracies for 0 - 200mV / 0 - 2V / 0 - 20V). The display ranges are 0.01 - 199.99mV / 0.1 - 1999.9mV / 1 - 19999mV respectively 5. Power: 3200W, maximum output voltage: 32V
Отправить запрос, связаться с поставщиком
Другие товары поставщика
 |
Fire stability tester for paper gypsum board | Fire stability tester for paper gypsum board - Other test instrument - standard Product Information: Technical parameters: 1, combustion tempera... |
 |
Face Mask Tensile Tester | Introduction: The test machine uses the integrated structure of the motor and the speed control system to drive the synchronous belt deceleration ... |
 |
20L Spherical Explosion Tester | The 20L Spherical Explosion Tester is a state-of-the-art laboratory instrument designed for the precise evaluation of the explosion characteristics... |
 |
Bean Bag Snag Tester | Bean Bag Snag Tester, to determine the snagging and picking resistance of knitted and woven fabrics by tumbling fabrics pillows containing a weight... |
 |
Photovoltaic module wire tube bending testing machine | Standard IEC 61730-2:2004: Photovoltaic (PV) Module Safety Qualification – Requirements for Testing CE Certification(Conformité Eu... |
