Catheter bending resistance tester

Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd

Все товары поставщика

Catheter bending resistance tester - Other test instrument - standard

Product Information:

Product introduction

　　The tester is composed of a programmable controller, a touch screen, a force sensor,

a transmission device, an airborne printer, etc. It provides a menu display in both Chinese

and English, and has a test mode for automatic operation of various parameters set by

man-machine dialogue. Test control range includes: nominal capacity, core rod displacement,

print setting, test, up, down, time, calibration, verification and other function Settings. With

the on-board printed test, the test load and sliding data （starting force, average force,

maximum thrust） can be displayed in real time. Automatically judge the test results, start

the automatic buzzer alarm if unqualified, and print out the test data and results by the printer

for analysis.

Test principle

　　The loop circumference of the catheter is expressed as the bending length, and the flow

rate of the catheter drainage cavity and the irrigation cavity is measured under the bending

length, so as to reduce the initial flow rate of the corresponding cavity after the flat catheter

is placed by 50%.

Technical parameter

　　1. Static level height: 1000±5mm, automatic circulation of water pump （adjustable

static water surface）

　　2. Time controller: 0-- 60min, error is not more than ±1S

　　3. Fixture: suitable for various catheters

　　4. Flow calculation: measuring cylinder method

　　5. Flow rate: >500ML/MIN

　　6. Overall size: 400×290×240（mm）
