Vibration Table

Vibration Table
  • Vibration Table
Производитель: Standard International Group (HK) Limited

Все товары поставщика
Отправить запрос, связаться с поставщиком

Standard

  • ASTM D999: Vibration testing of shipping containers and packaged products.
  • TAPPI T819: Corrugated box performance under simulated transport vibrations.
  • ISO 2247: Packaging—Complete, filled transport packages—Low-pressure vibration test.
  • ISTA 1A/2A: Standardized protocols for e-commerce and parcel shipping validation.

Product Advantages

1. Universal Testing Compliance

  • Multi-Standard Certification: Pre-configured profiles for global logistics requirements.
  • Regulatory Confidence: Meets Amazon, FedEx, and UPS carrier testing specifications.

2. Realistic Transport Simulation

  • Circular Vibration Mode: Mimics truck, rail, and aircraft vibration profiles.
  • 2–5 Hz Frequency Sweep: Replicates road roughness to port handling impacts.

3. User-Centric Operation

  • Digital Control Panel: LCD speed display with 0.1 Hz resolution.
  • Auto-Stop Counter: Programmable cycle limits (1–999,999 counts).

4. Adaptable Design

  • Modular Payload Capacity: 100–8,000 lbs (45–3,628 kg) load range for parcels to pallets.
  • Ergonomic Loading: Low-profile front ramp (8° incline) for forklift-free sample placement.

5. Industrial Durability

  • Abrasion-Resistant Deck: 12mm steel plate with diamond-hard coating.
  • Maintenance-Free Drive: Sealed motor system with 10,000-hour MTBF rating.

Product Features

  • Vibration System:
    • Synchronous Motor: 3-phase AC drive with 0.1 Hz frequency resolution.
    • Circular Orbit: 25.4mm (1”) amplitude for realistic transport simulation.
  • Control Interface:
    • 4.3” TFT touchscreen with pre-loaded ASTM/ISTA protocols.
    • USB port for test data export and firmware updates.
  • Safety Systems:
    • Emergency stop with E-Stop loop monitoring.
    • Overload protection at 110% of rated capacity.
  • Deck Configuration:
    • Adjustable rear bumper (0–300mm height adjustment).
    • Removable front guard for unobstructed sample access.
  • Mobility:
    • Heavy-duty casters with floor locks for stationary operation.
    • Forklift pockets for warehouse relocation.

Technical Parameters

SpecificationDetails
Frequency Range 2–5 Hz (0.1 Hz increments)
Max. Payload 100–8,000 lbs (45–3,628 kg)
Deck Size 1.2m × 1.2m (standard)
Amplitude 25.4mm (1”) circular orbit
Power Supply 220V/50Hz or 380V/3-phase (field-configurable)
Dimensions (W×D×H) 1,500mm × 1,500mm × 800mm (standard)
Weight 450 kg (net)

Accessories & Options

  1. Load Capacity Expansion:
    • Reinforced deck frames for 4,000–8,000 lbs payloads.
    • Distributed load spreaders for palletized testing.
  2. Software Add-Ons:
    • VibLog Pro™: Real-time FFT analysis and vibration spectrum logging.
    • Cloud Logistics: Remote monitoring for global supply chain teams.
  3. Calibration Services:
    • Annual recalibration with ISO 17025-accredited certificate.
  4. Safety Upgrades:
    • Seismic-rated anchoring system for high-risk zones.
    • Explosion-proof enclosure for hazardous environments.
  5. Consumables:
    • 1L High-temperature lubricant for motor maintenance.
    • 5 × Replacement deck anti-slip mats.
