Fiber Crimp Elasticity meter
Product Introduction:
YG362C fiber crimp elasticity meter is used for crimp degree of 1-22dtex fiber.
Crimp elasticity, crimp recovery rate index determination, natural fiber and chemical fiber crimp
Special testing instrument for fiber research, production and inspection departments.
Meet the standard:
GB/T14338-2008.
Product Advantages:
Standard Compliance: Conforms to the latest national standard GB/T 14338-2022 for testing the crimping performance of man-made staple fibers.
Broad Applicability: Suitable for a wide range of fiber linear densities (1-22 dtex) and applicable to both natural and chemical fibers.
Versatile Tension Loading: Offers multiple tension loader ranges (0-5.00mN, 0-10.00mN, 0-25.00mN) with fine minimum division values for precise control.
High Measurement Resolution: Provides a high displacement resolution of 0.01mm for accurate length changes.
Automated Testing: Features automatic timing with selectable durations (30s, 60s, 120s) for consistent and efficient testing.
Clear Observation: Equipped with LED lighting for enhanced visibility of the fiber sample during testing.
Comprehensive Analysis: Determines crimp degree, crimp elasticity, and crimp recovery rate, providing a complete profile of fiber crimp performance.
Supports Key Departments: An essential tool for fiber research, production, and inspection departments.
Technical parameters:
1. tension loader range :0-5.00mN(minimum division value 0.01mN)
0-10.00mN(min. 0.02mN)
0-25.00mN(min. 0.05mN)
2. Initial length :20mm
3. lower clamp stroke :≤30mm
4. displacement resolution :0.01mm
5. timing: automatic
6. timing :30s, 60s, 120s
7.lighting :LED lights
8.Crimp count length :25mm
9.Power supply: AC 220V 50HZ
