Electrical bushing flame retardant tester

•

Product Introduction:

The flame retardant test instrument for electrical bushing is used to measure the flame retardant performance of PVC cold formed insulating electrical bushing and accessories for construction. The equipment conforms to the specification of 6.10.1 "Self-extinguishing test" of insulating electrical bushing for construction in JG3050-1998 standard

And due to the requirements of the standard for the performance of the electrical bushing combustion tester itself.

Technical parameters:

1. the studio size WXHXD:300x1200x450mm

2. Outer box size WXHXD:320x1400x600mm

3. Gas: Liquefied petroleum gas (user's own)

4. Flame burning time and flame extinguishing time timing :0-999.9S 0.1s(timing accuracy :0.1S)， can be continuously set automatic record, manual pause

5. Bunsen burner tilt Angle :45°, adjustable in 0-90° range

6. Standard power of burner :1KW

7. nozzle (Bunsen burner) inner diameter :9mm

8. flame height :100mm blue cone flame core height :50mm

9. Working power supply :AC220V, 50Hz
