Medical injection needle tip puncture force tester
Производитель: Шанхайская компания Qianshi Precision Electromechanical Technology Co., Ltd
Все товары поставщика
Все товары поставщика
Medical injection needle tip puncture force tester - Other test instrument - standard
Standards:
GB15811-2016 "Disposable Sterile Injection Needle"
Applications:
Product Information:
Product characteristics
Using 7-inch K600+ core/dot-matrix 65 color 800*480 resolution touch screen display,
PLC control system dynamically displays the loading force value; Operation interface
Optional: Chinese/English/English switch; Digital closed loop control, AD acquisition speed
is 500KHz, internal code is 500000; High precision clock chip, power off storage; Overload
alarm stop protection; Touch operation: nominal specifications, tubes, test times, pressure,
up, down, time, calibration. Real-time display of piercing force and peak force data, can display
the maximum piercing force and F five peaks, and printed by the on-board printer test results.
Technical parameter
1. Nominal specification :0.18——3.4mm;
2. Test range :0——5.00N, error is not more than 0.5%; Resolution :0.001N
3. Moving speed :100mm/min; The error is not more than 5%;
4. Printing method: Each time can print 8, 13 or 20 times of test data and average puncture
force and difference.
5. Shipping list: 1 set of host, 1 certificate, 1 fixture, 1 operation manual, 1 roll of printing
paper, supporting weights.
6. Power supply :AC90V-240V/50Hz
7. Data storage: on-board needle printer/U disk can be imported to computer storage
8. Net weight :10kg Dimensions :300x240x240（mm）
9. Services: Non-standard instruments can be customized
10. The instrument is free to upgrade service and maintain for life according to national standards
