Hexapod Tumbler test machine

Application

  • Textile Industry: Assesses carpet pile integrity for residential, commercial, and automotive applications.
  • Quality Control: Validates compliance with international appearance change standards.
  • Research & Development: Tests material resistance to abrasion, crushing, and pile distortion.
  • Certification Labs: Provides data for SATRA, ISO, and BSEN certification.

Standard

  • BSEN 1471:1997: Evaluation of Appearance Changes in Floor Coverings
  • ISO 9405:2001: Floor Coverings – Determination of Appearance Change After Simulated Traffic
  • ISO 10361:2000: Carpet Appearance Evaluation Using Tumbler Testers
  • IWS/Wools of New Zealand Methods 247 & 251: Pile Fabric Abrasion Resistance

Product Advantages

  1. Realistic Wear Simulation: Reciprocating mechanism replicates foot traffic and pile compression.
  2. Rapid Testing: Completes substrate-based barrel tests within one working day.
  3. Adjustable Parameters: Preset rotations (0–999,999 cycles) via digital counter.
  4. Replaceable Components: Polyurethane hexapod feet (3.8 kg) last 2+ years and are easily replaceable.
  5. Safety Design: Hinged cover with sensors prevents accidental access during operation.
  6. Global Compliance: Meets BSEN, ISO, and IWS standards for carpet performance.

Product Features

  • Hexapod Foot Design: Six polyurethane feet (3.8 kg total) mimic human walking pressure.
  • Reciprocating Drum: Rotates at 35 ±2 RPM to simulate bidirectional traffic.
  • Substrate Testing: Accommodates steel balls or textile samples in the 200 mm deep chamber.
  • Digital Control: Touchscreen panel for cycle preset, speed adjustment, and real-time monitoring.
  • Easy Maintenance: Quick-release hexapod feet and corrosion-resistant stainless steel drum.
  • Wall Thickness: 8 mm drum construction ensures durability.

Technical Parameters

ParameterSpecification
Control Panel Touchscreen Timing Module
Hexapod Foot Weight 3.8 kg (Six Polyurethane Feet)
Power Consumption 0.5 kW
Rotational Speed 35 ±2 RPM
Drum Internal Depth 200 ±1 mm
Cycle Counter Range 0–999,999 (Presettable)
Wall Thickness 8 mm (Stainless Steel)
Power Supply AC 220V ±10%, 50Hz
Dimensions (L×W×H) 900 mm × 500 mm × 570 mm
Net Weight 75 kg
Safety Cover Hinged with Sensor Interlock
