Programmable Sutherland ink rub tester for R&D and QC
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Testing ink abrasion resistance on printed materials
Evaluating surface wear performance of paper and cardboard
Performing dry abrasion, wet abrasion, and transfer friction tests
Supporting product development and production quality control
Conducting standardized testing in teaching and research laboratories
Standards
ASTM D-5264-92: Standard Test Method for Abrasion Resistance of Printed Matter
GB/T 7705-2008: National Standard for Offset Decorative Printed Matter
Technical Specifications
| Item | Parameter |
|---|---|
| Power Supply | 220V / 50-60Hz / Single Phase / 2A |
| Dimensions | 15 × 15 × 12 inches |
| Weight | Gross 42 lbs |
| Speed Settings | Speed 1: 21 rpm Speed 2: 42 rpm Speed 3: 85 rpm Speed 4: 106 rpm |
| Count Range | 0–999 cycles (presettable) |
| Slider Weights | Standard: 2 lbs (0.9 kg), 4 lbs (1.8 kg) Optional: 20 N weight |
| Display | LCD |
| Functions | Dry abrasion, wet abrasion, wet smear or transfer, functional friction tests |
| Automatic Features | Auto power-off, end-of-test notification |
Accessories
| Accessory / Consumable | Description |
|---|---|
| Slider Weights | Standard 2 lbs and 4 lbs; optional 20 N weight; custom weights available |
| Safety Cover | Protects operators from rotating components |
| Power Cord | Standard 220V |
| User Manual | Operation and maintenance guide |
| Tools | Adjustment and installation tools |
Testing Principle
The Double-Head Abrasion Tester simulates actual wear and color transfer by driving friction sliders to reciprocate across the sample surface using a motor. The interaction between the sliders and the surface generates friction, allowing you to evaluate abrasion resistance and ink adhesion under different speeds, weights, and cycle counts.
