Laboratory car wash simulator for automotive testing
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Laboratory Car Wash Simulator is a specialized testing system designed to replicate automatic car wash conditions under controlled laboratory environments. You can use it to evaluate coatings, paint protection films, and plastic components by applying repeated mechanical stress through rotating brushes, controlled sample movement, and spraying of synthetic soiling agents. This allows you to assess abrasion resistance, scratch resistance, and appearance changes in materials during simulated car wash processes.
Standards
The simulator supports compliance with the following international standards:
ISO 20566:2021 – Paints and varnishes – Laboratory-scale car wash machine testing.
ISO 13076 – Visual assessment of coating surface appearance.
ISO 2813 – Measurement of gloss of coatings.
ISO 13803 – Measurement of haze of coatings.
ISO 7724 – Color measurement and color difference evaluation of coatings.
Parameters
| Parameter | Details |
|---|---|
| Dimensions | W3100 × D950 × H1800 mm |
| Weight | ~450 kg |
| Main Body Material | SUS 304 stainless steel |
| Test Environment Temperature | 23 ± 3 ℃ |
| Test Environment Humidity | 50 ± 5 %RH |
| Test Medium | Clean water + silicon dioxide |
| Medium Temperature | 15 – 30 ℃ |
| Brush Direction | Clockwise / Counterclockwise |
| Brush Speed | 70 – 127 ± 5 rpm |
| Brush Cycles | 1 – 999 cycles |
| Wash Liquid Capacity | 80 L |
| Sample Thickness | 1.5 – 3.5 mm |
| Sample Size | 155 × 305 mm (up to 4 pieces) or 310 × 610 mm (1 piece) |
| Platform Speed | 5.0 ± 0.2 m/min |
| Spray Flow Rate | 2.2 ± 0.2 L/min |
| Spray Pressure | 300 ± 50 kPa |
| Power Supply | AC 220 V, 2.2 kW, 50 Hz |
Accessories
Silicon dioxide powder – 500 g
Poly-fiber wash brushes – 2 rolls
Calibration plates – 10 pieces
Spray nozzles, 316 stainless steel – 2 pcs
Hex keys – 1 set
Wrenches – 1 pcs
User manual (Chinese) – 1 copy
Certificate of conformity – 1 copy
Warranty card – 1 copy
