Automotive Control Cable Fatigue Tester for Flexible Shaft Systems
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
The Automotive & Motorcycle Control Cable (Flexible Shaft) Fatigue Tester is designed to evaluate the durability and fatigue performance of automotive and motorcycle control cables. By simulating repeated force and reciprocating motion experienced during actual use, it quantitatively assesses structural stability, service life, and reliability under defined loads and cycles, providing reliable data for design validation and quality control.
Application
This tester is applicable to a wide range of vehicle control cables and flexible shaft assemblies, including but not limited to:
(1) Automotive throttle cables
(2) Automotive clutch cables
(3) Automotive brake cables
(4) Automotive gear shift cables
(5) Automotive parking brake cables
(6) Motorcycle throttle cables
(7) Motorcycle clutch cables
(8) Motorcycle brake cables
(9) Bowden cables and flexible shaft assemblies
(10) Control cables for electric vehicles, light vehicles, and specialty vehicles
Suitable for: automotive manufacturers, motorcycle production facilities, cable/component manufacturers, third-party testing labs, and research institutions.
Standards
(1) QC/T 29101-92 — Automotive Cable Assemblies
(2) QC/T 228.10-1997 — Motorcycle and Moped Control Cable Test Method
(3) SAE J193 — Automotive Control Cable Reference Test Method
(4) ISO 6722 — Reference Principles for Cable and Component Durability Testing
Parameters
| Item | Technical Specification |
|---|---|
| Maximum Cable Load | 5000 N |
| Reciprocating Stroke | ±50 mm |
| Reciprocating Frequency | 30 / 60 cycles per minute |
| Test Cycle Range | 0–999.999 cycles |
| Test Cycle Accuracy | ±0.5% |
| Load Application | Pulley mechanism + standard weight + spring |
| Motion Conversion | Crank-slider mechanism |
| Drive | Dual-speed motor |
| Power Supply | AC 380V ±10% (3-phase) / AC 220V ±10% (single-phase) |
| Control | Electro-mechanical |
| Display | Digital counter display |
Accessories
| Name | Description |
|---|---|
| Pulley Assembly | Guides the cable along the test path |
| Standard Weights | Apply initial load to the cable |
| Standard Springs | Alternate load between initial and maximum force |
| Cable Fixtures | Secure cables of various sizes |
| Magnetic-Electric Sensor | Detects test cycle count |
| Power Cable | Supplies electrical power |
| Fasteners | Bolts, nuts, and connection components |
