OEM Yellowing resistance test chamber
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
Applications
Test method for determining the yellowing resistance of light and white products, such as upper and bottom materials for shoes, to approximate sunlight and ultraviolet light. According to the light-colored or white products, the phenomenon of yellow color is easy to occur in the natural sunlight for a long time, with the solar lamp and heating temperature control device to simulate the natural environment, within the specified time, observe the change of the surface color of the sample, determine the degree of discoloration of the sample, so as to determine the ability of the material to resist yellow under sunlight radiation.
Standards
HG/T3986:Plastic tower filler
ASTM D1748-24:Standard Test Method for Rust Protection by Metal Preservatives in the Humidity Cabinet
Features
This machine is designed to promote the metamorphism of vulcanized materials and then calculate the rate of change, stretching, and elongation. It also simulates the effects of ultraviolet radiation and heat from the sun. Samples are placed on the machine's table and subjected to UV radiation and temperature. Over time, the degree of yellowing and discoloration of the samples is observed, and the grayscale values can be used as a reference to determine the extent of yellowing. This is relevant to products that are exposed to radiation or sunlight during transportation.
The machine addresses the impact of color changes in the container environment on product quality. Using a 300W UV lamp, the experiment can be completed in a shorter time. This machine can be used as a basic yellowing resistance testing machine, an aging testing machine, and an oven, demonstrating its multi-functional capabilities. The machine is equipped with a forced hot air circulation control system to ensure uniform temperature distribution.
Technical Parameters
| Parameter | Specification |
|---|---|
| Light source | 300W UV light bulb imported from Germany |
| Temperature range | Room temperature +5℃ —— 200℃ |
| Temperature uniformity | ±2℃ |
| Electric heating power | 500W and 1000W two groups |
| Temperature control | LED digital display, PID temperature controller |
| Time control | 0——9999min or 0——9999h |
| Test frame | diameter 400mm, speed 1——20rpm adjustable, single-layer test frame |
| Working rate size | 500x500x600mm(WxDxH) |
| Dimensions | 500x500x600mm(WxDxH) |
| Power supply | AC220V, 1.8KW |
Accessoriess
Stainless steel test panel, high-temperature resistant observation window, single-layer test rack assembly, operating manual + certificate of conformity, power cord, fuse.
