ASTM E662 FTIR Smoke Toxicity Analyzer Manufacturer
Get a quote：
Whats/App: +86 156 1874 6768
Web: standard-groups.com
E-mail：info@standard-groups。com
Parameters
| Item | Specification |
|---|---|
| Quantifiable Gas Species | More than 300 compounds |
| Spectral Range | 4500–800 cm⁻¹ |
| Spectral Resolution | Better than 1 cm⁻¹ |
| Gas Analysis System | Multi-pass gas cell with 5 m optical path |
| Working Pressure | 0–15 bar |
| Maximum Working Temperature | Up to 191 °C |
| Dedicated Filter | Filters dust particles ≥ 2 μm |
| System Integration | 19-inch standard industrial chassis |
Features
Wide application flexibility, enabling gas measurements under different pressure and temperature conditions through appropriate accessories.
Optimized high-throughput optical design of the gas cell allows quantitative analysis of mixed gases even at concentrations as low as the ppb level.
No gas calibration is required; the system software automatically retrieves target gas concentrations using nonlinear fitting algorithms.
Effects caused by interfering gases and temperature variations are automatically compensated, ensuring accurate real-time qualitative and quantitative results.
Optical system employs a thermoelectrically cooled detector, CenterGlow™ infrared light source for stable high emission, and a RockSolid interferometer to ensure permanent optical alignment.
Equipped with dedicated sampling probes for gas extraction from pipelines or sealed chambers.
Independent and complete gas analysis software package with an intuitive graphical user interface.
Enables fast, continuous, and fully automated gas identification and quantification without requiring specialized user expertise.
Accessories
(1) Multi-pass gas cell with 5 m optical path
(2) Dedicated gas sampling probe
(3) Dust filtration unit (≥ 2 μm)
(4) Integrated interferometer module
(5) Infrared light source and detector assembly
(6) Industrial control and analysis software package
(7) 19-inch industrial chassis and mounting components
Test Procedures
System Preparation
Install the FTIR system in a stable environment and ensure the gas cell, filter unit, and sampling probe are correctly connected.
Sampling Setup
Insert the dedicated sampling probe into the pipeline, test chamber, or smoke outlet where gas collection is required.
Software Configuration
Launch the gas analysis software and select the corresponding measurement or monitoring mode according to the test objective.
Gas Measurement
Gas samples are continuously introduced into the multi-pass gas cell, where infrared spectra are collected and processed in real time.
Data Analysis and Output
The software automatically performs qualitative identification and quantitative analysis of gas components and displays real-time concentration results, which can be stored or exported for further evaluation.
