Dynamic Shear Rheometer
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Dynamic Shear Rheometers are configured to meet the demands of everyday quality control testing of 4, 8, and 18mm samples in asphalt production facilities. These models are ideal for the classification of SHRP/Superpave PG binders.
A disc-shaped binder sample is confined between two parallel plates and subjected to horizontal oscillation to determine dynamic shear properties. The synchronous, brushless DC motor drives a rotor mounted on a frictionless air bearing to allow the most precise movement and sensitive measurements. An operation requires a clean, dry, and oil-free supply of compressed air.
Standards：
ASTM D4402 、ASTM D7175 、ASTM D7405 、ASTM D4402 M、ASTM P246
EN 14770 、EN 13702 、EN 16659
AASHTO M320-10 、AASHTO M332-14 、AASHTO T315 、AASHTO T316 、AASHTO R29 、AASHTO T391 、AASHTO T350-14
JTG E20-2011 T0628、
Technical Parameters：
| Torque range | 0.001-200mNm |
| Torque resolution | 0.001mNm |
| Normal force range | 0.01-50N |
| Normal force resolution | 1mN |
| Test plate | 1pair8mm& 1pair25mm (can be customized) |
| Rotating speed | 0.01-2850r/min |
| Angular velocity range | 0.01-300rad/s |
| Deflection angle resolution | 10-4rad |
| Vibration frequency range | 0.1-10Hz |
| Temperature range | 5-85℃ |
| Temperature resolution | 0.01℃ |
| Temperature control accuracy | ±0.1℃ |
| Bearings | Porous carbon magnetic thrust bearings |
| Power supply | 220VAC50Hz |
