Battery Slurry Resistance Tester

Whats/App: +86 156 1874 6768

Web: standard-groups.com

The Battery Slurry Resistance Tester is a precision testing system designed to measure the resistivity of high-solid battery slurries and conductive coatings. By providing rapid, accurate, and non-contact resistivity measurements, the system ensures quality control, process monitoring, and R&D optimization in battery manufacturing. It is widely used by battery material developers, electrode manufacturers, and testing laboratories for inline production monitoring, performance evaluation, and compliance verification.

Application

(1) Measurement of resistivity in lithium-ion, sodium-ion, and solid-state battery slurries.

(2) Quality control of cathode/anode slurry consistency in battery electrode production.

(3) Evaluation of conductive coatings, including carbon black, graphite, and conductive additives.

(4) Inline monitoring of slurry stability during mixing, coating, and drying processes.

(5) R&D optimization of electrode formulations for improved ionic conductivity and energy density.

(6) Temperature-dependent resistivity testing with automated viscosity compensation.

(7) Integration with PLC/SCADA or IoT platforms for real-time process feedback.

(8) Predictive diagnostics of slurry stability using AI-driven trend analysis.

Standards

(1) ASTM B193 – Standard Test Method for Resistivity of Electrical Conductor Materials.

(2) ISO 18516 – Conductive Coatings – Measurement of Resistivity.

(3) IEC 62660-3 – Secondary Lithium-Ion Cells, Part 3: Safety Requirements.

(4) RoHS Compliance – Restriction of Hazardous Substances.

(5) CE Certification – Conformité Européenne for electrical safety and EMC compliance.

Features

(1) Sub-milliohm sensitivity for high-solids slurries (0.1 mΩ·cm).

(2) Non-contact gap-sensing electrodes to eliminate contamination risks.

(3) High-speed measurement: 2-second test cycle for inline production monitoring.

(4) Auto-cleaning system with solvent-resistant nozzles to prevent cross-contamination.

(5) 7” HD glove-compatible touchscreen with multi-language interface (10 languages).

(6) QR code-enabled data export for instant sharing.

(7) Chemical-resistant 316L stainless steel enclosure with PTFE coating.

(8) IP65-rated for dust, splash, and cleaning agent resistance.

(9) IoT-enabled real-time data streaming via OPC UA.

(10) AI-driven predictive diagnostics for slurry stability assessment.

(11) Dynamic temperature control (-20°C to 80°C ±0.2°C) via built-in Peltier module.

(12) Multi-frequency DC/AC measurement (1 Hz – 10 kHz) with viscosity compensation for slurries up to 10.000 cP.

(13) Laser-guided probe immersion depth control (±0.05 mm).

(14) Emergency shutoff via magnetic reed switch.

Parameters

Parameter	Specification
Resistance Range	0.1 mΩ – 200 Ω (auto-ranging)
Accuracy	±0.2% of reading + 0.05 mΩ
Test Voltage	10 mV – 10 V (programmable)
Sampling Rate	10.000 points/s
Temperature Control	-20°C to 80°C (±0.2°C)
Data Interface	Ethernet, USB 3.0. Wi-Fi 6. Bluetooth 5.2
Power Supply	100–240V AC, 50/60 Hz (universal adapter)
Dimensions (W×D×H)	350 × 300 × 180 mm
Weight	15 kg (net) / 18 kg (gross)
