- Diesel engine 50HP; loading capacity :700KG
- Italy pump; Eaton drive motor
- Italy valves ; Mechanical leveling
- Mechanical control
<
| Model | SSL45 |
|---|---|
| Rated capacity (kg) | 700 |
| Tipping load(kg) | 1400 |
| bucket capacity (cbm) | 0.4 |
| lifting force (kg） | 1950 |
| Hydraulic pump flow (L/min) | 75 |
| Engine power (HP) | 50 |
| Weight(kg) | 3100 |
| Max traveling speed (km/h) | 12 |
| Grade ability (degrees) | 20 |
| Tire | 10-16.5 |
| Fuel/hydraulic oil tank (L) | 60/60 |
| A.Height at maximum extension | 3670mm |
| B.Hinge pin height | 2900mm |
| C. Total height | 2050mm |
| D. length with bucket | 3420mm |
| E. length without bucket | 2640mm |
| F. Width with bucket | 1740mm |
| G. Track width | 1450mm |
| H. Wheel base | 991mm |
| J.Ground clearance | 185mm |
| K. Dumping angle | 40 degree |
| L.Dumping height | 2230mm |
| M.Maximum Reach | 710 |
