MTUB43-90511B-12A20 Mini USB Female Connector
This model is a Mini USB R/A T/H DIP female connectorthat complied with RoHS certificate. It adopts shell LCP UL94V-0 flame-retardant material and terminal with copper alloy gold-plated, and is specially designed for electronic devices that that require right angle connections. and is particularly suitable for industrial equipment and consumer electronics products with limited space.
Features
90°R/A DIP design: save lateral space and is suitable for compact layouts
Insertion and extraction force standard: insertion force ≤3.57kgf, extraction force≥0.7kgf, ensure stable connection and easy to maintain.
Terminal holding force≥1.0kgf: To prevent welding detachment.
LCP UL94V-0 shell: high-temperature resistance and flame-retardant, it is superior to ordinary PA raw material.
The shell is nickel-plated( material SPCC/C2680 ): enhance wear resistance.
As a trusted USB connector manufacturer,We specializes in designing and producing a complete range of USB Type-A, Type-B, Micro-USB, Mini-USB, and Type-C connectors.
Send product request
Other supplier products
 |
MTFP85-406SWN-56220 6Pin ZIF FPC Connector | This 6Pin FPC connectorfeatures a ZIF (Zero Insertion Force) structure with bottom-contact design, a pitch of 0.5mm, and a height of 2.0mm. Its 90&... |
 |
MTFH63-211GRB-11A36 11Pin PH1.27mm Vertical Dual Row Female Header | This dual-row vertical surface-mount (SMT) gold-plated headerfeatures a 1.27mm pitch design with 11 pins per row (22 pins total), optimized for hig... |
 |
MTBH44-207GA0-21132 2.0mm Box Header | This product complies with RoHS standard, Box Headeradopts high-density pitch design of 2.0mm. It particularly design for high-density PCB connecto... |
|
|
MTUB43-90511B-12A20 Mini USB Female Connector | This model is a Mini USB R/A T/H DIP female connectorthat complied with RoHS certificate. It adopts shell LCP UL94V-0 flame-retardant material and ... |
 |
MTPH23-210GR0-24A29 10Pin PH1.27mm DIP Dual-row Pin Header | This 10Pin dual-row through-hole (DIP) pin headerfeatures a 1.27mm pitch design with 10 pins per row (20 pins total), designed for high-density PCB... |
Same products
|
|
MTUB43-90511B-12A20 Mini USB Female Connector | Seller: MTCONN ELECTRONICS CO.,LTD | This model is a Mini USB R/A T/H DIP female connectorthat complied with RoHS certificate. It adop... |
 |
Radar RD03 | Seller: Xi'an Interwiser Electronic Technology Co., Ltd | The RD03 low-altitude surveillance radaris a Ku-band phased array radar that adopts an all-solid-... |
 |
IWRFSOC8X8 Xilinx RFSoC 3U 4-Channel/ DC-4GHz | Seller: Xi'an Interwiser Electronic Technology Co., Ltd | InterWiser IWRFSOC8x8 3U algorithm evaluation modular systemdesigned for integration into deploye... |
 |
