Cable Reel Trailer,Reel Cable Trailer,Pulley Carrier Trailer, Pulley Trailer

Product description: This product is the new generation of cable trailer, which integrates the function of drum hauling, cable pulling, cable pushing, guiding and tighting into a whole. Equipped with automatic braking device, it can brake effectively only by moving clutch. With compact design and flexible steering function, it can be operated under narrow work site. Simple operation and easy maintenance, it is a necessary tool for electric power construction.

Product No.

HT1003-3

HT1003-5

Power:

11kw

18kw

Rated payload

3T

5T

Cable pulling/pushing speed

1200m/h

1200m/h

Rated traction force

20kn

40kn



≤φ2300mm

≤φ2800mm



≤1300mm

≤1500mm

Overall dimension (length*width*height)

3300mm×2450mm×1850mm

3800mm×2700mm×2200mm

Dead weight

1250kg

2100kg



Product No.

Rated load

Applicable drum diameter

Applicable drum width

Axle bar diameter

HT1012-3

3T

≤φ2400mm

≤1400mm

φ76mm

HT1012-5

5T

≤φ2800mm

≤1600mm

φ90mm

HT1012-8

8T

≤φ3400mm

≤1800mm

φ120mm

HT1012-10

10T

≤φ3600mm

≤2000mm

φ150mm



Dimension of main body

Product No.

Dimension of main body

HT1012-3

3800mm×2300mm×2000mm

HT1012-5

4000mm×2600mm×2200mm

HT1012-8

4300mm×3200mm×2400mm

HT1012-10

4600mm×3800mm×2600mm
