EE pure epoxy powder coating

Surface Finish Options Overview

Product description

Made with epoxy resin as the main raw material, it has excellent chemical resistance and mechanical properties.

Application areas:

Suitable for coating metal products with high requirements for corrosion resistance, electrical insulation and flexibility. It is generally not recommended to be used directly for surface coating of various outdoor products.

Physical properties:

1. Specific gravity: 1.2-1.8 (depending on color and gloss)

2. Storage: Below 25℃, in a dry environment, it can be stored for 6 months if the packaging is intact.

3. Packaging: 15 kg/box, carton packaging, lined with two layers of polyethylene inner bags.

Coating performance:

Spraying area 8-12 m2/Kg, film thickness 70μm (100% powder usage rate)
Adhesion GB/T 9286 Grade 0
Impact GB/T 1732 50cm
Cupping test GB/T 9753 ≥ 6 mm
Bending test GB/T 6742 ≤ 3 mm
Pencil hardness GB/ 6739 ≥ H
Salt spray test GB/T 1771 1000 h passed
Moisture and heat resistance GB/T 1740 1000 h passed

Application instructions:

Surface treatment: Treat according to the substrate and required performance

Spraying: electrostatic gun or friction gun

Film thickness: 60-70 um

Curing conditions: Workpiece temperature/time: 140-200℃ x 15 minutes (depending on the specific product)

Health and safety:

This powder coating is a non-toxic product, but dust should be avoided during use. Operators are advised to wear appropriate dust masks and glasses. If possible, try to avoid long-term contact between skin and powder coating.

Safety and Protection

All dust is irritating to the respiratory system, so avoid inhaling dust and steam generated during curing. Take measures to avoid skin contact. If contact is necessary, wash the skin with water and soap. If contact with the eyes, wash immediately with clean water and seek medical attention in time. Avoid the deposition of dust and powder particles on the surface and dead corners. Tiny organic particles will ignite and explode under static electricity. All equipment must be grounded to prevent static electricity.
