Powder coating for automobile wheels MT-Al00
Product Overview:
Special powder coating for wheels (rims), a series of epoxy polyester powder coating products specially designed for the characteristics and requirements of wheel base and topcoat.
Coating characteristics:
—Strong adhesion
—Excellent leveling
—High air permeability
—Good salt spray resistance
Application:Suitable for automotive aluminum wheels and steel rims
Application parameters:
Curing time: 180℃~200℃, 10~15 minutes
Spraying method: High-voltage electrostatic spraying 60~80KV
Coating performance:
| Project | Instrument | Judgment standard | Test standard |
| Pencil hardness | Pencil hardness tester | 1H | GB/T 6739
ASTM D3363 |
| Impact resistance | Impact tester | 50 kg.cm (8mm diameter)
2.5Nm (16mm diameter) (20mm diameter) |
GB/T 1732 ASTM D 2794 ISO 6272 |
| Bending resistance | Bending tester | W 2mm (cylindrical shaft)
Conical shaft bending Cylindrical shaft |
GB/T 6742 ASTM D 1737 ISO 1519 |
| Adhesion | Hundred grid test | Grade 0 | GB“ 9286 ISO 2409 ASTM D 3359 |
| Salt spray resistance | NSS salt spray | &1000H, WbS2mm | GB/T 1771 ASTMB-117 ISO 7253 |
| Cupping | Cupping instrument | & 6 mm | GB/T9753 ISO 1520 |
•The above tests are all conducted on 0.8mm degreased and derusted cold-rolled steel plates, with a coating thickness of 60~80um. The performance indicators of the coating will vary slightly with the gloss.
Environmental protection requirements: This product does not contain heavy metals such as chromium, selenium, lead, hexavalent chromium, mercury, lock, cadmium, etc., and fully complies with ROHS2.0 environmental protection requirements.
If you're ready to take the next step or Request Free Samples, Leave your message below and we’ll reply soon. 20+ years of chemical manufacturing & export experience, a partner you can trust.
