EP hybrid powder coating/polyester tgic powder coating
Product description
It is made of epoxy resin and polyester resin as the main raw materials, and has their own unique properties, so that the produced coating has excellent leveling, decorative, mechanical properties and strong corrosion resistance.
Application areas:
Widely used in the coating of various indoor metal products.
Physical properties:
1. Specific gravity: 1.2-1.8 (depending on color and gloss)
2. Storage: Below 35℃, in a dry environment, it can be stored for 12 months if the packaging is intact.
3. Packaging: 20 kg/box, carton packaging, lined with two layers of polyethylene inner bags.
Coating performance:
| Spraying area | 8-12 m2/Kg, film thickness 70μm (100% powder usage rate) | |
| Adhesion | GB/T 9286 | Grade 0 |
| Impact | GB/T 1732 | 50cm |
| Cupping test | GB/T 9753 | ≥ 6 mm |
| Bending test | GB/T 6742 | ≤ 3 mm |
| Pencil hardness | GB/ 6739 | ≥ H |
| Salt spray test | GB/T 1771 | 1000 h passed |
| Moisture and heat resistance | GB/T 1740 | 1000 h passed |
Application instructions:
Surface treatment: Treat according to the substrate and required performance
Spraying: Electrostatic gun or friction gun
Film thickness: 60-70 um
Curing conditions: Workpiece temperature/time: 180℃ x 15 minutes
Hygene & Safety:
This powder coating is a non-toxic product, but dust should be avoided during use. Operators are advised to wear appropriate dust masks and glasses. If possible, try to avoid long-term contact between skin and powder coating.
