3D Textured Wood Grain Powder Coating

3D Textured Wood Grain Powder Coating is a high-end decorative coating designed to provide a realistic, three-dimensional wood grain appearance. Unlike conventional thermal transfer printing, this coating is applied using a dedicated large-scale vertical automatic spraying production line. Through a multi-layer coating and baking process combining basecoat and topcoat, you achieve a relief effect with strong visual depth and authentic wood texture to the touch. The coating can incorporate both matte and glossy wood grain effects, making it ideal for premium doors, windows, and architectural applications where aesthetics and durability are critical.

Application

You can use 3D Textured Wood Grain Powder Coating in applications where a realistic, high-end wood-like appearance is required, including:

• Premium residential and commercial doors and window frames

• Decorative façade panels and cladding systems

• Architectural aluminum profiles for interior and exterior use

• High-end furniture frames and architectural fixtures

Test Substrate:The coating is typically evaluated on 0.8 mm degreased and derusted aluminum or steel panels suitable for multi-layer powder coating processes.

Parameters

Item	Description
Coating Type	3D textured wood grain powder coating
Surface Effect	Three-dimensional relief with matte or glossy finish
Application Method	Automatic vertical multi-layer electrostatic spraying
Curing	Basecoat + topcoat multi-layer baking
Recommended Film Thickness	60–150 µm per layer, depending on substrate and texture depth
Environmental Compliance	Free of heavy metals, RoHS-compliant

Note: Specific curing times and film thicknesses should be optimized based on substrate type and production line parameters.

Features

• You achieve athree-dimensional wood grain effectwith strong visual depth and realistic tactile texture

• You can selectmatte or glossy finishesfor customizable aesthetic appeal

• You benefit fromexcellent outdoor durability, suitable for architectural exterior applications

• You gainscratch resistance and mechanical stability, ensuring the coating maintains its appearance over time

• The multi-layer system allowsuniform coverage on edges, corners, and profiles

Case

We helped a premium residential door manufacturer enhance their product line. By applying the 3D Textured Wood Grain Powder Coating on aluminum door frames, you achieved a visually striking wood effect without the maintenance issues of real wood. The matte relief surface reduced glare and increased perceived quality. After 12 months of outdoor exposure testing in a coastal environment, the coating retained its color, gloss, and three-dimensional texture, meeting both aesthetic and durability requirements.
